P-0183-001 - 第211页
MODEL TCM-X300S 0306-001 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 209 MA-8 70 1 630 1 16 0283 CO VE R 1 814MA-010-701 70 2 630 1 18 7228 MEC H P ART S(C OVE R) 1 814MA-010-702 70 2 -01 630 1 19 1928 ME CH P A R …
MODEL TCM-X300S
0306-001
208
ࠞࡃㇱ COVER SECTION
Fig. MA-8 ೨㕙ోᚺ Front Safety Door
705
749
748
747
733
740
741
721
731
742
743
744
742
731
723
705
746
706
707
707
715
711
738
738
725
739
740
734
718
717
741
740
705
746
727
743
742
735
743
742
735
734
726
728
745
738
732
724
722
706
707
715
711
707
730
742
743
730
742
743
716
729
742
735
736
720
714
743
742
730
714
743
742
730
704
701
704
737
720
719
702
702-07
702-01
702-04
702-05
702-02
702-06
702-03
702-52
702-54
702-53
702-51
702-08
MODEL TCM-X300S
0306-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
209
MA-8
701 630 116 0283 COVER 1 814MA-010-701
702 630 118 7228 MECH PARTS(COVER) 1 814MA-010-702
702 -01 630 119 1928 MECH PARTS(FRAME) 1
702 -02 630 119 1935 MECH PARTS(FRAME) 1
702 -03 630 119 1942 MECH PARTS(FRAME) 1
702 -04 630 119 1959 MECH PARTS(FRAME) 1
702 -05 630 119 1973 COVER 1
702 -06 630 119 2147 MECH PARTS(CAP) 4
702 -07 630 118 0243 BRACKET 1
702 -08 630 119 2130 MECH PARTS(HOLDER) 1
702 -51 630 000 7763 BOLT,HEX-SCT 2
702 -52 630 065 2499 BOLT,HEX-SCT 8
702 -53 411 008 2109 WASHER SPR 5 2
702 -54 630 029 1391 WASHER 2
704 630 013 8986 MECH PARTS(RUBBER CUSHION 2 814MA-010-704
705 630 118 8966 SUPPORT 2 814MA-010-705
706 630 115 4206 PIN,HINGE 2 814MA-010-706
707 630 008 1985 RING 4 814MA-010-707
711 630 106 8916 SUPPORT 2 814MA-010-711
714 630 119 8668 SUPPORT 2 814MA-010-714
715 630 118 8973 SUPPORT 2 814MA-010-715
716 630 038 9715 PIN,HINGE 2 814MA-010-716
717 630 089 3694 COLLAR 2 814MA-010-717
718 630 096 9344 MECH PARTS(URETHANES) 2 814MA-010-718
719 630 119 6770 PLATE 1 814MA-010-719
720 630 003 5032 HANDLE 1 814MA-010-720
721 630 120 4789 BRACKET 1 814MA-010-721
722 630 118 6849 BRACKET 1 814MA-010-722
723 630 120 2686 SWITCH,LIMIT 1 SQ8,21052 814MA-010-723
724 630 095 7914 PLATE(ACTUATOR) 1 814MA-010-724
725 630 119 6756 BRACKET 2 814MA-010-725
726 630 096 9023 SUPPORT 2 814MA-010-726
727 630 115 4411 SUPPORT 2 814MA-010-727
728 630 104 4507 HINGE 2 814MA-010-728
729 630 029 1391 WASHER 4 814MA-010-729
730 630 000 7763 BOLT,HEX-SCT 8 814MA-010-730
731 630 000 7756 BOLT,HEX-SCT 6 814MA-010-731
732 630 000 7732 BOLT,HEX-SCT 2 814MA-010-732
733 630 000 7695 BOLT,HEX-SCT 2 814MA-010-733
734 630 000 7626 BOLT,HEX-SCT 6 814MA-010-734
735 630 000 7763 BOLT,HEX-SCT 10 814MA-010-735
736 411 140 7406 SCR FLT 5X20 2 814MA-010-736
737 411 113 7501 SCR TRS 4X10 2 814MA-010-737
738 411 113 9109 SCR TRS 5X10 8 814MA-010-738
739 630 001 0213 WASHER 4 814MA-010-739
740 411 141 2905 WASHER SPR 4 8 814MA-010-740
741 411 141 4008 WASHER V 4X9X0.8 4 814MA-010-741
742 411 141 6705 WASHER SPR 5 26 814MA-010-742
743 411 141 4107 WASHER V 5X10X1 20 814MA-010-743
744 630 001 0220 WASHER 2 814MA-010-744
MODEL TCM-X300S
0306-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
210
MA-8
745 630 000 8920 SET SCREW 4 814MA-010-745
746 411 002 2600 SCR FLT 3X6 4 814MA-010-746
747 630 000 7510 BOLT,HEX-SCT 4 814MA-010-747
748 411 141 2806 WASHER SPR 3 4 814MA-010-748
749 411 141 3902 WASHER V 3X7X0.5 4 814MA-010-749
