E-by SIPLACE CP12 & CP6 Move to Servi ce Positi on and Shut Down Ma chine Part Exchange 1/2 CAUTION! Refer to safety inst ructions in user manual before working on the machine. ESD guidelines are to be followed Tool:…

E-by SIPLACE CP12 & CP6 Move to Service Position and Shut Down Machine

Part Exchange

1/2

CAUTION! Refer to safety instructions in user manual before working on the machine.

ESD guidelines are to be followed

Tool: Wear Part: Consumables:

1. Click on "stop production" icon. 2. Click on "check sensors and functions"

icon.

3. Click on "move gantry 1 to service position"

icon.

4. Press start button. 5. Click on "setting options conveyor interface

and shut down" icon.

6. Click on "shut down the machine" icon.

E-by SIPLACE CP12 & CP6 Move to Service Position and Shut Down Machine

Part Exchange

2/2

CAUTION! Refer to safety instructions in user manual before working on the machine.

ESD guidelines are to be followed

Tool: Wear Part: Consumables:

7. Switch off machine. 8. Open cover. 9. Carefully move gantry into working area.

Check for obstruction before move.
