SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
10
3 Prerequisites
NOTICE
System requirements
The Support Media DVD included in the installation package checks the necessary
system requirements of your system and installs these. Amongst others e.g. Microsoft
.NET Framework, the License Manager and the Error Reporting tool.
The use of the Support Media V1.14 is obligatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the SIPLACE Support Media
Installation Manual, item no. [00197214-xx].
SIPLACE Pro requires an NTFS partition for the installation. FAT or FAT32 file systems are not
supported.
3.1 LINUX/ UNIX Line Computer
The import / export functions of SIPLACE Pro support the following versions of the LINUX / UNIX
line computer:
– LRU.501.xx
– LRU.502.xx
– LRU.503.xx
The following files can be imported from the line computer to SIPLACE Pro and from SIPLACE Pro
to the line computer:
– *.be files (Components)
– *.sgf files (Component Shapes)
– *.ri file (Restrictions: Component/Component Shape – Feeder Type)
– *.qd files (Boards)
– *.pm files (Fiducials)
– *.rt files (Setups)
SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
11
3.2 Supported Platforms, Station Software Versions and Machine
Types
Platform Station Software
Version
Machine Types
70x
706
DX-series: DX1, DX2 and DX4
SX-series: SX1/SX2, SX1/SX2 V2 and SX4
X-series: X2, X3, X4 and X4i
X-series S: X3 S, X4 S and X4i S
705
DX-series: DX1, DX2 and DX4
SX-series: SX and SX4
X-series: X2, X3, X4 and X4i
704 SX-series: SX and SX4
X-series: X2, X3, X4 and X4i
703 SX-series: SX
X-series: X2, X3, X4 and X4i
702 X-series: X2, X3, X4 and X4i
701 X4i
Plattform II +
605 CA-series: CA3, CA4
D-series: D1, D2, D3, D4
X-series: X2, X3, X4
604
604
D-series: D1, D2, D3, D4
X-series: X2, X3, X4
603 D-series: D1, D2, D3, D4
X-series: X2, X3, X4
602 D- series: D3, D4
X-series: X2, X3, X4
601 X-series: X2, X3, X4
Plattform II 505 HF
HF/3
HS50
HS50+ (optional)
HS60
S25HM
S27HM
504 HF
503 HS50
HS50+ (optional)
HS60
S25HM
S27HM
SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
12
Platform Station Software
Version
Machine Types
502 HS50
S25HM
Plattform I 408 S23
F5HM
CS
CF
407 S20
S23
F4
F4-6
F5
F5HM
C-Series 408 CF
CS
101 CF
CS
