SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
11
3.2 Supported Platforms, Station Software Versions and Machine
Types
Platform Station Software
Version
Machine Types
70x
706
DX-series: DX1, DX2 and DX4
SX-series: SX1/SX2, SX1/SX2 V2 and SX4
X-series: X2, X3, X4 and X4i
X-series S: X3 S, X4 S and X4i S
705
DX-series: DX1, DX2 and DX4
SX-series: SX and SX4
X-series: X2, X3, X4 and X4i
704 SX-series: SX and SX4
X-series: X2, X3, X4 and X4i
703 SX-series: SX
X-series: X2, X3, X4 and X4i
702 X-series: X2, X3, X4 and X4i
701 X4i
Plattform II +
605 CA-series: CA3, CA4
D-series: D1, D2, D3, D4
X-series: X2, X3, X4
604
604
D-series: D1, D2, D3, D4
X-series: X2, X3, X4
603 D-series: D1, D2, D3, D4
X-series: X2, X3, X4
602 D- series: D3, D4
X-series: X2, X3, X4
601 X-series: X2, X3, X4
Plattform II 505 HF
HF/3
HS50
HS50+ (optional)
HS60
S25HM
S27HM
504 HF
503 HS50
HS50+ (optional)
HS60
S25HM
S27HM
SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
12
Platform Station Software
Version
Machine Types
502 HS50
S25HM
Plattform I 408 S23
F5HM
CS
CF
407 S20
S23
F4
F4-6
F5
F5HM
C-Series 408 CF
CS
101 CF
CS
SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
13
3.3 Supported Feeder Types
The following feeders are supported by SIPLACE Pro:
– 4 mm – 104 mm X-feeder
– 2x8 mm X-feeder
– 16 mm XN-feeder
– 12 X-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– Glue Feeder
– TrayStak Feeder AX (X4i S on location 2 and 3 only)
– Arbitrary Carrier X (X-series only)
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– FFI feeders:
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE multi stick 60 AX
IPTE multi stick XL80 AX
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Dip module for X-tables (LDU_X)
– MTC2 (X2, X3, X4 on location 2 and 4, X3 S on location 2, X4 S)
– WPC5 (only SX1/SX2)
– WPC6 Non Stop Module (SX1/SX2 only)
– Splice sensor X-feeder
