SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
12
Platform Station Software
Version
Machine Types
502 HS50
S25HM
Plattform I 408 S23
F5HM
CS
CF
407 S20
S23
F4
F4-6
F5
F5HM
C-Series 408 CF
CS
101 CF
CS
SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
13
3.3 Supported Feeder Types
The following feeders are supported by SIPLACE Pro:
– 4 mm – 104 mm X-feeder
– 2x8 mm X-feeder
– 16 mm XN-feeder
– 12 X-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– Glue Feeder
– TrayStak Feeder AX (X4i S on location 2 and 3 only)
– Arbitrary Carrier X (X-series only)
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– FFI feeders:
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE multi stick 60 AX
IPTE multi stick XL80 AX
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Dip module for X-tables (LDU_X)
– MTC2 (X2, X3, X4 on location 2 and 4, X3 S on location 2, X4 S)
– WPC5 (only SX1/SX2)
– WPC6 Non Stop Module (SX1/SX2 only)
– Splice sensor X-feeder
SIPLACE Pro V10.1 SP1 / Software Version Description Ausgabe 02/2013 Edition
14
3.4 New Positions and Supported PCB Widths for Fixed Rails in
SX1/SX2 V2
The following new positions and PCB widths have been implemented for fixed rails in the SX1/SX2
V2 conveyor system:
Fixed Rail Fixed Rail Position PCB Width Distance of Fixed
Rail
Right/Left
Outer
268 250 286
536
Right/Left
259.7
242
277.2
Table 3-1: Fixed rail positions in SX1/SX2 V2
The outer rail position may be set in SIPLACE Pro but is not supported by the 60x station software.
