Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer
Edition 06/2011 EN 3.1 Initial Installation of SIPLACE Explorer 2.9
27
(2) Support Media DVD:
The system will be checked for the required software components and their versions. You will
see the result of this check in a notifications window and can then install any missing
components via this option. 3
The following software components are included on the support media DVD and will be
installed when required: 3
– J2SE Runtime Environment 6 update 1 or higher
Install Java 6 update 1 on the same computer as SIPLACE Explorer V.2.9. 3
– Tomcat 5.5
– MS XML Core Services 6.0
Install these components if you wish to generate factory reports and reports for certain
production lines. 3
– SQL Server 2008 Express Edition
– Microsoft Internet Explorer 6.0 SP2 or 7.0
Microsoft Internet Explorer is required to view and edit websites. 3
Microsoft Internet Explorer 6.0 SP2 is included on the Support Media DVD, MS Internet
Explorer 7.0, installed with the Windows Vista installation. 3
– Adobe Reader 7.0
This component is needed for reading the SIPLACE Explorer V.2.9 documentation. Adobe
Reader 7.0 is included on the Support Media DVD. 3
For a detailed description of the specified installations, refer to the document “Navigation
Guide for the Installation Procedure of SIPLACE Software Systems” (Art.No. 00195050-xx). 3
Consider the following before beginning the installation: 3
NOTE
Before installing Tomcat 5.5, make sure that all versions of Tomcat < 5.5 have been
uninstalled. Use the Apache Tomcat uninstallation program. This can be started via the
Start Programs Apache Tomcat 5.5 Uninstall Tomcat menu in Windows. 3
3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer
3.1 Initial Installation of SIPLACE Explorer 2.9 Edition 06/2011 EN
28
NOTE
You will need to specify the following information when installing Tomcat 5.5:
- Port number for Tomcat: By default, Tomcat is installed on port 8080. This means that your
users will access your website as follows:
http://yourServerName:8080/yourWebsite/index.jsp.
- Access data for the Tomcat administrator:
User name: admin
Password Policy: depending on the selected password policy, you need to enter a
password: MS128 or Siplace.1.
This password is needed for website generation.
This login will automatically be used as default login for Line Configuration - Step 7 "Website
Generation". 3
NOTE
Before you install SIPLACE Explorer V2.9, make sure that Java 1.6 has been installed on
your computer. Install this software component via the support media DVD. 3
(3) SIPLACE Explorer V.2.9 options:
The options SIPLACE Traceability Option V2.0 and SIPLACE Maintenance Manager V1.0 are
not included in the SIPLACE Explorer V2.9 delivery package and must be ordered (installed)
separately. 3
(4) SIPLACE Explorer V.2.9 installation:
Proceed as described in “Installation of SIPLACE Explorer 2.9” on page 30. 3
Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer
Edition 06/2011 EN 3.2 Update Installation of SIPLACE Explorer 2.9
29
3.2 Update Installation of SIPLACE Explorer 2.9
To update from a previous version to SIPLACE Explorer V2.9, you must already have an
executable version of SIPLACE Explorer already installed on your system. 3
– Update from SIPLACE Explorer V2.0 - V2.8 to SIPLACE Explorer V2.9:
Uninstall the previous version with its components. Proceed by following the instructions at
“Uninstallation” on page 105. For the installation, proceed as described at “Initial Installation of
SIPLACE Explorer 2.9” on page 25 3
NOTE
If you want to keep the existing line configurations and other settings, install the new version
of SIPLACE Explorer in the same folder as the previous version. See Fig. 3 - 6 SIPLACE
Explorer Setup - "Choose Folder" dialog box. 3
NOTE
Before installing Tomcat 5.5, make sure that all versions of Tomcat < 5.5 have been
uninstalled. Use the Apache Tomcat uninstallation program. This can be started via the
Start Programs Apache Tomcat 5.5 Uninstall Tomcat menu in Windows. 3
NOTE
If you have an English operating system, the Asian language must be installed. Otherwise
SIPLACE Explorer can not display the tray menus correctly after you have set the user
interface to an Asian language. SIPLACE Explorer displays ???.
Proceed as described in “Adjusting the Regional Settings for Asian Languages” on page 42.3
