2 Operational safety User manual E by SIPLACE
2.11 ESD guidelines From software version SC 712.1 Edition 05/2019
100
Do not move the assemblies near to data view devices, monitors or television units. Keep a min-
imum distance of > 10 cm to monitors.
2.11.4 Measurements and modifications to ESD modules
Do not take measurements on the modules unless the following conditions are fulfilled:
– the measuring device is earthed (e.g. via PE conductors) or
– you discharge the measuring head just before taking measurements with a potential-free
measuring device (e.g. by touching an unpainted metal part of the controller casing).
Always use an earthed soldering iron if you carry out any soldering work.
2.11.5 Dispatching ESD modules
Always store modules and components in conductive packaging (e.g. metallized plastic bags
or metal sleeves) and dispatch them in conductive packaging.
If the packaging is not conductive, place the modules in a conductive envelope before pack-
aging. Use conductive expanded rubber, ESD bags, domestic aluminum foil or paper, for ex-
ample. NEVER use plastic bags or film. 2
If the module has integral batteries, ensure that the conductive packaging does not touch or
short-circuit the battery terminals and, if necessary, first cover the terminals with insulating
tape or material.
User manual E by SIPLACE 3 Technical data and assemblies
From software version SC 712.1 Edition 05/2019 3.1 Overview of technical data
101
3 Technical data and assemblies
3.1 Overview of technical data
3.1.1 Placement head configuration - optimum values
3.1.2 Placement machine - optimum values
3
Placement Head CP14 CP12 CP12/PP
*a
*)a The max. component length is the diagonal value of the max component size indicated.
CP6/PP
a
TH
a
E-Component
Range
01005 to
6 x 6mm
01005
*b
to
18.7 x 18.7 mm
*)b Optional with 01005 package CP12 E
01005 to
45 x 98 mm
0201 to
45 x 98 mm
0201 to
200 x 110 mm
E-Component
Height
4 mm 7.5 mm 19 mm 19 mm 25 mm
E-Accuracy (3σ) 41µm 41µm 37.5µm 37.5µm 22µm
E-Speed 45,300 cph 24,300 cph 24,200 cph 13,700 cph 5,200 cph
IPC
*c
Speed
*)c IPC specification base on 01005.
25,000 cph 14,700 cph 14,700 cph 9,500 cph 4,400 cph
Placement
Machine
E by SIPLACE
Heads CP14 CP12 CP12/PP CP6/PP TH
Board format
(length
*a
x width)
*)a With „Long board“ option
1200 mm x 460 mm
Feeder capacity 120 x SIPLACE SmartFeeder 8 mm E
PCB thickness 0.3 - 4.5 mm
PCB weight
*b
*)b The board weight value refers to the weight of the board plus the weight of the components
up to 2 kg
Air Consumption 90 NL/Min. 90 NL/Min. 140 NL/Min. 140 NL/Min. 185 NL/Min.
Machine dimen-
sion (L x W)
*c
*)c Without changeover table or fixed table
1,500 mm x 1,666mm
Machine
weight
*d
*)d Single sided machine
1,850 kg
3 Technical data and assemblies User manual E by SIPLACE
3.1 Overview of technical data From software version SC 712.1 Edition 05/2019
102
3.1.3 Component camera configuration
3.1.4 Component feeding
3
Placement
head 1
Component
Camera 1
Placement
head 2
Stationary
Component
Camera 1
*a
*)a Optional, type 33 GigE
Stationary
Component
Camera 2
*b
*)b Optional
SIPLACE CP14 Type 23 GigE -- -- --
SIPLACE CP12 Type 30 GigE -- -- --
SIPLACE CP12 Type 30 GigE SIPLACE PP Type 36 GigE Type 25 GigE
SIPLACE CP6 Type 30 GigE SIPLACE PP Type 36 GigE Type 25 GigE
-- -- SIPLACE TH Type 36 GigE Type 25 GigE
Feeder locations
Changeover table with 60 tracks
Fixed table with 60 tracks
60 feeders with SIPLACE SmartFeeder 8mm E
60 feeders with SIPLACE SmartFeeder 8mm E
Changeover table changeover time < 1 minute
Max. component feeding
E by SIPLACE double sided
E by SIPLACE single sided
120 locations for feeders with SIPLACE SmartFeeder 8mm E
60 locations for feeders with SIPLACE SmartFeeder 8mm E
Feeder module types
(E by SIPLACE)
SIPLACE SmartFeeder E
SIPLACE StickFeeder E
SIPLACE Component Reject Conveyor E
Label Feeder (OEM Product)
Bowl Feeder (OEM Product)
Manual Tray holder E (Speed)
Manual Tray holder E (Flex)
SIPLACE JTF-MW
Feeding capacity
(2 change over tables on the E by
SIPLACE)
120 tape feeder modules, SIPLACE SmartFeeder 8 mm E
60 tape feeder modules, SIPLACE SmartFeeder 2x8 mm E
60 tape feeder modules, SIPLACE SmartFeeder 12 mm E
60 tape feeder modules, SIPLACE SmartFeeder 16 mm E
40 tape feeder modules, SIPLACE SmartFeeder 24 mm E
30 tape feeder modules, SIPLACE SmartFeeder 32 mm E
24 tape feeder modules, SIPLACE SmartFeeder 44 mm E
20 tape feeder modules, SIPLACE SmartFeeder 56 mm E
16 tape feeder modules, SIPLACE SmartFeeder 72 mm E
*a
12 tape feeder modules, SIPLACE SmartFeeder 88 mm E
a
*)a On request
