User manual E by SIPLACE 3 Technical data and assemblies From software version SC 712.1 Edition 05/2019 3.2 Ambient condi tions and connection values 105 3.2.4 Compressed air supply and c ompressed air specification 3 Co…
3 Technical data and assemblies User manual E by SIPLACE
3.2 Ambient conditions and connection values From software version SC 712.1 Edition 05/2019
104
3.2 Ambient conditions and connection values
3.2.1 Ambient conditions for packaging, transportation and storage
3
3.2.2 Ambient conditions for machine operation
3
3.2.3 Electrical ratings
3
3
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75 % (no higher than 45% on average to prevent any
possibility of condensation on the machine)
Ambient pressure > 890 mbar (corresponds to 1000 m above mean sea level)
PLEASE NOTE
Use of a residual current protection device
The low ground leakage current of the system makes it possible to use an upstream
residual current protection device at the customer end. This must be all-current sen-
sitive (RCD type B).
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 200 V~ up to 3 x 230 V~; ± 10 %; 50/60 Hz)
*a
3 x 380 V~ up to 3 x 415 V~; ± 10 %; 50/60 Hz
3 x 16 A characteristic C
*b
3 x 16 A characteristic C
*b
Mains power connection Cable 4 x 4 mm² with CEKON connector
Energy consumption
Energy consumption
with
vacuum pump
Nominal active power
1.8 kW
Nominal apparent power
2.3 kVA
*)a With adapter kit (US option)
*)b Usage worldwide (except North America): e.g. Siemens circuit breaker 5SY8 316-7
or
EATON Industries circuit breaker (miniature circuit breaker) FAZ-C16/3 16 A 3p
For North America: e.g. Siemens circuit breakers in accordance with IEC and UL 489 (order no.: 5SJ4 316-7HG42)
or
EATON Industries circuit breaker FAZ-C16/3-NA 16A 3p (UL 489, CSA C22.2 no. 5, IEC 60947-2)
User manual E by SIPLACE 3 Technical data and assemblies
From software version SC 712.1 Edition 05/2019 3.2 Ambient conditions and connection values
105
3.2.4 Compressed air supply and compressed air specification
3
Compressed air supply
Compressed air pressure values
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air connection R 3/4" inner thread (pipe thread) with 1/2" hose connection
Compressed air consumption
*a
Placement head configura-
tion
Compressed air
consumption
*b
with
vacuum pump
*c
E by SIPLACE CP14
CP12
CP12 / PP
CP6 / PP
TH
90 Nl/min
90 Nl/min
140 Nl/min
140 Nl/min
185 Nl/min
Compressed air specification according to DIN ISO 8573-1:2010
Particle size (ISO class 1) 0.1 µm
Particle density (ISO class 1) 0.1 mg/m³
Maximum oil content (ISO class 1) 0.01 mg/m³
Pressure dewpoint (ISO class 4) + 3°
*)a Average consumption values
*)b Under normal atmospheric conditions at 20°C and 1013 hPa.
*)c Vacuum pump for SIPLACE CP14/CP12/CP6 head only.
3 Technical data and assemblies User manual E by SIPLACE
3.3 Dimensions and weight From software version SC 712.1 Edition 05/2019
106
3.3 Dimensions and weight
3.3.1 Technical data - dimensions and weight
3
Length of the machine
E by SIPLACE
E by SIPLACE with LBO1200
1500 mm
1910 mm
Width of the machine
E by SIPLACE 1666 mm
Height of the machine
with indicator lamp
With folded-up protective covers
(for PCB conveyor height 900 mm)
(for PCB conveyor height 930 mm)
(for PCB conveyor height 950 mm)
max. 1760mm
1750 mm
1780 mm
1800 mm
Machine ground clearance
(for PCB conveyor height 900 mm)
(for PCB conveyor height 930 mm)
(for PCB conveyor height 950 mm)
120 mm ± 15 mm
150 mm ± 15 mm
170 mm ± 15 mm
Weight of E by SIPLACE
Single sided
Double sided
1850 kg
2050 kg
Weight of component table
Changeover table 60
Changeover table 60 (fully configured)
Fixed table 60
Fixed table 60 (fully configured)
88 kg
138 kg
53 kg
104 kg
Floor space for E by SIPLACE
Single sided with 1 x changeover table 60
Double sided with 2 x changeover table 60
2.835 m²
3.338 m²
Floor stiffness
Minimum vertical floor stiffness
Recommended vertical floor stiffness
0,5E8 N/m
≥ 1,5E8 N/m
The load per unit area calculation included an additional working space of 0.5 m on each side
of the machine.
Load per unit area for E by SIPLACE
Single sided
Double sided
5.02 kN/m²
5.04 kN/m²
Number of machine feet 4
