5.2.2 Controls on the machine's operator panels
All the controls can be reached by a 1.40 m tall person. There is a monitor and a keyboard on both
sides of the machine.
The start and stop buttons are located near the keyboard. The on-screen dialog will occasionally
prompt you to activate certain actions using buttons, and this arrangement will make it easier for
you both to activate and to interactively control these actions.
Main switch 5
The main power switch is used to switch the power supply to the machine on and off.
5
Stop button (black) 5
This button is used to stop the machine.
Start button (white) 5
This button starts the machine after it has been switched on or after faults have been eliminated.
EMERGENCY STOP button 5
The EMERGENCY STOP button latches in the ON position when pressed. The power supply to
the gantry axes, the changeover tables, conveyors and used tape cutters is interrupted and the
voltage supplied to the star axes of the placement heads is reduced. Turn the button to release it.
LCD touchscreen 5
There is a flat LCD screen with a touch-sensitive surface (touchscreen) on either side of the place-
ment machine.
DANGER
Lethal voltages!
Some parts inside the machine carry potentially lethal voltages - even when switched off
at the main power switch.
User manual E by SIPLACE 5 Working with the machine
From software version SC 712.1 Edition 05/2019 5.2 Controls and displays
205
Keyboard 5
The keyboard is located beneath the monitor.
5
Optional indicator lamp with buzzer - three color (red/yellow/green) 5
The sequence of colors of the indicator lamps is red - yellow - green. These lamps are used to
signal operating statuses and malfunctions of the machine. The buzzer indicates when an alert
has occurred. See also Section 5.8 on page 222.
Indicator lamp with buzzer - two color (white/green) - optional 5
The sequence of colors of the indicator lamps is white - green. These lamps are used to signal
operating statuses and malfunctions of the machine. The buzzer indicates when an alert has oc-
curred. See also Section 5.8 on page 222.
CAUTION
Risk of collision on the monitor with keyboard
When working on the changeover table, there is risk that you could collide with the monitor
and keyboard.
Turn the monitor and keyboard away to the side.
Make sure that you are not under the monitor and keyboard with your head.
5 Working with the machine User manual E by SIPLACE
5.3 Switching on the Machine From software version SC 712.1 Edition 05/2019
206
5.3 Switching on the Machine
5.3.1 What to consider before switching on the station
5
Check whether the station is connected to the power and compressed air supplies.
Perform a sight check of the station. Make sure that there are no obstacles in the travel range
of the gantries.
Make sure that the Z axes of all heads are in their uppermost end positions.
5.3.2 User classification
Certain functions or menus may only be executed. A differentiation is made between the following
operator levels:
– Basic production
– Advanced production
– Machine service
The operator levels Advanced production and Machine service can be password protected.For a
detailed description of the user classification, refer to section 5.1
, page 199.
5.3.3 Switching on the station and starting the station software user interface
Switch the station on at the main power switch.
After switching on, check whether the manometers show the required operating pressure.
– The station computer software is loaded and the "Production" view of the station software
is shown (see following diagram).
CAUTION
Before you switch on the station, please perform the following steps.
