5 Working with the machine User manual E by SIPLACE

5.16 Docking the changeover table in or out From software version SC 712.1 Edition 05/2019

254

I 5

 Connect the power cable and the D-sub connection cable of the changeover table to the ma-

chine

 Carefully push the changeover table into machine as far as the stop.

 Go to the main view of the station software and select the Feeder module... icon and

then the

Locations icon.

 Click on the icon to lock the respective location and wait until the trolley has docked

completely. For further information, refer to the station software Online Help.

PLEASE NOTE

Cut tapes flush

If you do not cut tapes off flush at the front end of the SIPLACE SmartFeeder E, the emp-

tied tapes will not enter the empty tape duct.

 Cut the tapes off flush, before you dock the changeover table into place.

CAUTION

Position of placement head!

Check that the placement head is outside the range of the changeover table.

CAUTION

Risk of head crash!

When dismantling one of the two brackets (left and right side) for the table height check,

there is a risk of a head crash due to changeover tables being too high.

 Do not dismantle the brackets.

PLEASE NOTE

 Close the protective covers since the changeover table can only be docked in if the

covers are closed.

User manual E by SIPLACE 6 Station extensions

From software version SC 712.1 Edition 05/2019 6.1 Nozzle changer

255

6 Station extensions

For the relevant configurations and other options, refer to the individual specifications for the E by

SIPLACE machines.

6.1 Nozzle changer

Nozzle changers can greatly increase the flexibility of the placement heads for processing differ-

ent types of component. If the placement program requires a nozzle change, then the placement

head automatically returns the old nozzle to the nozzle holder and picks up the new nozzle. Noz-

zles that were separated out during the vacuum check can also be quickly changed.

It is significantly more exact and faster to pick up nozzles from a nozzle changer than would be

possible manually. When placing small components, it is essential to minimize the radial eccen-

tricity during nozzle rotation.

The basic design of the nozzle changer is identical for the Collect&Place heads

(SIPLACE CP14/12/6). However, make sure that you always use the correct nozzle magazines

for the specific head.

6 Station extensions User manual E by SIPLACE

6.1 Nozzle changer From software version SC 712.1 Edition 05/2019

256

6.1.1 Nozzle changer for the SIPLACE CP14

Item no. 03113147-xx Nozzle changer E by SIPLACE, CP14 for location 1

Item no. 03113193-xx Nozzle changer E by SIPLACE, CP14 for location 2

Item no. 03101503-xx Magazine for 1 x 20 nozzles for nozzle type 4xxx

Fig. 6.1 - 1 Nozzle changer for the SIPLACE CP14 (example)

(1) Nozzle changer magazin 4xxx

(2) Nozzle changer

(3) Component reject bin

(2)

(3)

(1)
