User manual E by SIPLACE 6 Station extensions From software version SC 712.1 Edition 05/2 019 6.11 SIPLACE Comp onent Reject Conveyor E 313 6.11.4 Safety Instructions Please ensure that all safety ins truct ions in this …
6 Station extensions User manual E by SIPLACE
6.11 SIPLACE Component Reject Conveyor E From software version SC 712.1 Edition 05/2019
312
6.11.3 Technical data
– Dimension:
– Width 80mm
– Height 213.7 mm (excluding knurled knob, max height 17.5 mm at fully retracted)
– Length 611 mm
– Location on E by SIPLACE:
– Occupies 7 omega rail tracks and can be placed anywhere on the table, both Location 1
and Location 2
– Component sizes:
– Maximum weight: 100 gr
– Minimum Height: 1 mm
– Minimum Size: 3 x 1.4 mm
– Maximum Height: 19 mm
– Maximum Size: 60 x 60 mm
– Pitch Settings:
– Component height 10 - 19 mm ' Set to pitch 0 ' Conveyor will index 268 mm
– Component height less than 10 mm ' Set to pitch 1 - 9 ' Conveyor will index 10 - 100 mm,
to be selected depend on component's size.
– Communication
– Pogo-pin Interface
– Weight
– max 5.5 kg
User manual E by SIPLACE 6 Station extensions
From software version SC 712.1 Edition 05/2019 6.11 SIPLACE Component Reject Conveyor E
313
6.11.4 Safety Instructions
Please ensure that all safety instructions in this section have been followed.
6
CAUTION
Safety of Operators and Other Persons
– Machine operators may only carry out work for which they have been adequately trained and
with which they are totally familiar!
– NEVER open one of the protective covers if you are not totally familiar with the use and func-
tion of this machine!
– The protective covers may only be opened during operation if you are requested to do so in
this Manual or by a dialog in the station software!
– Never remove this module from the changeover table while the host machine is in operation.
– Never make changes, however minor, unless you are totally aware of the effect they will
have on the overall functioning of the system.
– This machine must always be set-up, retooled and maintained by appropriately trained per-
sonnel.
– Only use original spare parts and authorized accessories of ASM Assembly Systems. The
use of other parts will affect safety and can invalidate the liability for any consequential dam-
age.
– Do not make modifications to the safety equipment, in particular NEVER deactivate circuit-
breakers or remove safety devices.
– For your own safety, wear work clothes that conform to the guidelines of the professional
association, i.e. no wide sleeves, etc.
– Reduce the risks by not wearing scarves, chains or ties at your work post.
– People with long hair must wear a protective head covering.
– Always follow the safety regulations specific to your country!
WARNING
Voltage
This machine is electrically driven. When electrical devices are in use, certain parts carry a voltage of
25Vdc!
Before performing any work on parts which conduct electricity, switch the placement machine off
at the main switch and unplug the Harting connector to remove power to this module.
There is a risk of fatal injuries, severe injuries and/or considerable damage to equipment if any of
these instructions are not followed!
6 Station extensions User manual E by SIPLACE
6.11 SIPLACE Component Reject Conveyor E From software version SC 712.1 Edition 05/2019
314
WARNING
Safe operation of module
In spite of all the safety precautions taken by the manufacturer, failure to use the module as prescribed
can result in severe physical injury and/or considerable damage to equipment!
For the machine to be safe, it must be used correctly by qualified personnel and all warnings must be
observed. Some work requires training that goes beyond the scope of this Manual.
