7 Maintenance User manual E by SIPLACE
7.1 Safety Information From software version SC 712.1 Edition 05/2019
316
7
7
7
7
CAUTION
Filter elements
The cleaning and checking intervals given for inspecting and replacing the filter
elements only apply to the specified compressed air quality (see
Section 3.2.4 on
page 105
). If other qualities are used, the intervals should be shortened accord-
ingly.
CAUTION
Ethanol
Always wear safety goggles and gloves when using concentrated ethanol to clean
modules.
If ethanol should accidentally get into your eyes, rinse your eyes immediately with
water.
CAUTION
Consumable materials
Observe the safety data sheets for consumable materials.
CAUTION
Cleaning and lubrication
Always use ethanol for cleaning - do not use solvents.
NEVER use compressed air to clean units inside the placement machine or modules.
User manual E by SIPLACE 7 Maintenance
From software version SC 712.1 Edition 05/2019 7.2 Maintenance on Base Machine
317
7.2 Maintenance on Base Machine
7
Base machine Every 6
months
Every 12
months
– Checking the Fans on the MGCU
X
– Checking the safety features on machines
X
– Checking and Cleaning/Replacing (if required) the Compressed Air Filter
X
– Cleaning/Replacing the Head Exhaust Air Filter
X
– Greasing and clean the X axis guide bearing
X
– Cleaning the Linear Guides of the X Axis
X
– Grease and clean the Y axis guide bearing
X
– Cleaning the Linear Guides of the Y Axis
X
– Cleaning the X Axis Scale
X
– Cleaning the Y Axis Scale
X
– Cleaning the Protective Covers
X
– Checking/Cleaning/Replacing the Gas Pressure Shock Absorbers on the
Protective Covers
X
– Replace the loose bearing lubrication system X axis and Y axis (if pres-
ent)
X
– Grease and clean the X and Y axis guide bearing
X
7 Maintenance User manual E by SIPLACE
7.2 Maintenance on Base Machine From software version SC 712.1 Edition 05/2019
318
7
7
7
7
a) This value is for 3 shift operation (7500 hours of operation). Longer intervals can be planned for other operation setups.
Conveyor Every 6
months
Every 12
months
– Cleaning and Preserving the Conveyor
– Hexagonal shafts
– Linear guide rails
– Ball screws
– Guide shaft
X
Component Docking Unit Every 6
months
Every 12
months
– Function Test of Tape Cutter
X
– Greasing the Tape Cutter
X
– Greasing the Cutting Blade
X
– Greasing the COT Insert
X
– Greasing the Locator Bearing on the Component Trolley for SIPLACE
SmartFeeder E
X
Optical Systems Every 6
months
Every 12
months
– Cleaning the IC and FC Cameras
X
– Cleaning the PCB Barcode Scanner (if availible)
X
Cleaning and Checking tasks
Vacuum pump
Every 6
months
Every 12
months
– Checking/Replacing the Filter Insert
X
a
– Checking of the wear and tear of the vacuum vanes
X
a
