1.7.5.2 E by SIPLACE on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log onto our E by SIPLACE home page
at http://www.e-by-siplace.com.
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Registering for access to the User Group is easy:
Click on ’Register now’.
Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
1.7.6 Abbreviations
1
A-Placement Alternating Placement
PA Placement area
CO Component
CP14 SIPLACE CP14, Collect&Place head with 14 segments
CP12 SIPLACE CP12, Collect&Place head with 12 segments
CP6 SIPLACE CP6, Collect&Place head with 6 segments
DCA Direct chip attach
ESD Electrostatically-sensitive group of components
EMC Electromagnetic compatibility
ESD Electrostatic sensitive device
SC Single conveyor
FC Flip chip
GCU Gantry control unit
1 Introduction User manual E by SIPLACE
1.7 Important notes on the user manual From software version SC 712.1 Edition 05/2019
34
GND Ground
MHCU Machine/Head control unit
HMI Human machine interface (Operator panel)
JTF-MW JEDEC Tray Feeder (Automatic tray changer)
LBO Long Board Option
PCB Printed circuit board
MCS Machine capability study
P&P1 Pick&Place module 1 of the SIPLACE TH
P&P2 Pick&Place module 2 of the SIPLACE TH
NC Nozzle changer
SMD Surface mounted device
SC Station computer
TH SIPLACE TH, Twin Pick&Place head
PP SIPLACE PP, Pick&Place head
VS Vision system
User manual E by SIPLACE 2 Operational safety
From software version SC 712.1 Edition 05/2019 2.1 Safety instructions
35
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This user manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
2
2
2
2
DANGER
Definition
Danger, as used in this user manual, means that death, severe injury or considerable
damage to equipment will occur if the danger instructions are not followed.
WARNING
Definition
Warning, as used in this user manual, means that death, severe injury or considerable
damage to equipment may occur if the warning instructions are not followed.
CAUTION
Definition
Caution, as used in this user manual, means that slight injury or damage to equipment
may occur if the caution instructions are not followed.
PLEASE NOTE
Definition
A note, as used in this user manual, provides information on the product or indicates a part
of the user manual that requires particular attention.
