2 Operational safety User manual E by SIPLACE 2.2 Warning labels From software version SC 712.1 Edition 05/201 9 44 Fig. 2.2 - 4 Warning labels on the machine (single sided) - loca tion 2 - Grafic fehlt (1) Warning label…

100%1 / 324
User manual E by SIPLACE 2 Operational safety
From software version SC 712.1 Edition 05/2019 2.2 Warning labels
43
Fig. 2.2 - 3 Warning labels on the machine (single sided) - location 1
– W201, item no. 03009338-01
– W203, item no. 03009342-01
– W204, item no. 03009343-01
– W209, item no. 03009349-01
– W Laser Class 2, item no. 03134118-01
– W-General warning, label on the monitor from supplier
(T) Direction of PCB transport
W 209
W 204
W 203
W-General warning
W 201
W Laser Class 2
2 Operational safety User manual E by SIPLACE
2.2 Warning labels From software version SC 712.1 Edition 05/2019
44
Fig. 2.2 - 4 Warning labels on the machine (single sided) - location 2 - Grafic fehlt
(1) Warning label EMS (China), item no. 03113523-01
Or
(2) Warning label EMS (US), item no. 03113900-01
(T) Direction of PCB transport
– W203, item no. 03009342-01
– W-General warning, label on the monitor from supplier
2
1
2
W-General warning
W 203
WARNING
Damage to warning labels!
The warning labels can be damaged or destroyed by abrasive cleaning agents or solvents.
Do not use abrasive cleaners or solvents for cleaning warning labels.
Replace any damaged or illegible warning labels.
User manual E by SIPLACE 2 Operational safety
From software version SC 712.1 Edition 05/2019 2.2 Warning labels
45
2.2.1.1 Warning label W201
2
W201 in fig. 2.2 - 1, page 41, item no. 03009338-01
Quantity per machine:
E by SIPLACE double sided: 1 2
E by SIPLACE single sided: 1 2
2.2.1.2 Warning label laser class 2
2
W Laser class 2 in fig. 2.2 - 1, page 41 and 2.2 - 3, page 43, item no. 03134118-01
Quantity per machine:
E by SIPLACE double sided: 1 2
E by SIPLACE single sided: 1 2
