2 Operational safety User manual E by SIPLACE 2.2 Warning labels From software version SC 712.1 Edition 05/201 9 58 2.2.4.1 Warning label W205 on the used tape chute 2 Fig. 2.2 - 10 Warning label W205 on the used tape ch…
User manual E by SIPLACE 2 Operational safety
From software version SC 712.1 Edition 05/2019 2.2 Warning labels
57
2.2.4 Warning label W205 on the tape cutter
2
Fig. 2.2 - 9 Warning label W205 on the top of the tape cutter
– W205, item no. 03009344-01
2
WARNING
Risk of cuts!
Risk of cutting when working on the cutter!
Disconnect the machine from the power and compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
Wear robust protective gloves when working on the tape cutter.
W205
2 Operational safety User manual E by SIPLACE
2.2 Warning labels From software version SC 712.1 Edition 05/2019
58
2.2.4.1 Warning label W205 on the used tape chute
2
Fig. 2.2 - 10 Warning label W205 on the used tape chute
– W205, item no. 03009344-01
2.2.4.2 Warning label 205
Warning labels on tape cutter and used tape chute
2
W205 in fig. 2.2 - 9, page 57 and 2.2 - 10, page 58, item no. 03009344-01
Quantity per machine:
E by SIPLACE double sided: 4 2
E by SIPLACE single sided: 2 2
W205
2
2
2
2
2
2
2
2
RISK OF CUTTING!
Danger of cutting is present even when the machine is
switched off
User manual E by SIPLACE 2 Operational safety
From software version SC 712.1 Edition 05/2019 2.2 Warning labels
59
2.2.5 Warning labels on the SIPLACE SpeedStar C&P14
2
Fig. 2.2 - 11 Warning labels on the SIPLACE SpeedStar C&P14
(1) Temperature label, item no. 03031926-01
(2) Housing for the star motor
(3) Handle
Item W laser class 2, item no. 03134118-01
(1)
(2)
(3)
Laser class 2
