Instruction manual SIPLACE CA4 V2 1 Introduction From software version 713.0 Edition 12/2019 1.1 Important notes o n the instruction manual 13 1 Introduction This instruction manual is a gui de or reference work for op e…
Contents Instruction manual SIPLACE CA4 V2
From software version 713.0 Edition 12/2019
12
7.3 SIPLACE Wafer System (SWS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
7.4 Sensor for the component reject bin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .296
7.5 PCB barcode scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
7.5.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
7.5.2 Technical data - 2D code reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
7.6 Input conveyor and output conveyor extensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
7.6.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
7.7 SIPLACE JTF-S/JTF-M. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
7.7.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
7.7.2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
7.7.3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
7.8 Fixed component table for tray feeders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
7.9 Support pin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
7.10 Long board option (LBO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
8 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305
8.1 Safety instructions for maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306
8.1.1 Safety instructions for hazardous substances . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Instruction manual SIPLACE CA4 V2 1 Introduction
From software version 713.0 Edition 12/2019 1.1 Important notes on the instruction manual
13
1 Introduction
This instruction manual is a guide or reference work for operating and setting up the
SIPLACE
®
CA4 V2 placement machines.
– The SIPLACE CA4 V2 placement machine is available as a SIPLACE CA4 V2 variant with 4
gantries.
The header of each chapter contains the release and software version, to which this manual ap-
plies.
1.1 Important notes on the instruction manual
1.1.1 Contents and storage of the instruction manual
This instruction manual contains basic information that must be observed when setting up, oper-
ating and maintaining the machine. The service engineers, qualified staff, operators and users
plus system owner must therefore read it before commencing installation and commissioning. The
instructions must be kept permanently accessible where the placement machine is used.
In addition, the user must ensure that the employees have fully understood the contents of the
instruction manual.
1.1.2 Danger notes
1
WARNING
Read the instruction manual!
Tasks may only be performed by qualified staff who have completed the relevant
training.
Only perform tasks on the placement machine if you have precise knowledge of the
relevant section in the instruction manual.
Observe all warnings, caution notes and hazard notes.
Please also read chapter 2 of this instruction manual through carefully.
1 Introduction Instruction manual SIPLACE CA4 V2
1.1 Important notes on the instruction manual From software version 713.0 Edition 12/2019
14
1.1.3 Manufacturer's/supplier's liability
We hereby confirm that the contents of this instruction manual are of a descriptive and explanatory
nature only and do not contain any contractual conditions or guaranties. The liability and obliga-
tions assumed by ASM Assembly Systems GmbH&Co.KG can be found exclusively in the rele-
vant contract agreement concerning the supply of the placement machine described in this
manual. This applies in particular to all statements regarding performance or service life and the
agreed liability for faults or defects. The provisions of the contract regarding the liability for faults
or defect are neither extended nor restricted by any statements in this instruction manual.
1.1.4 Revision table
1
1.1.5 Further information about and contents of the documentation package
1.1.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems GmbH&Co.KG
Rupert-Mayer-Str. 44
81379 Munich 1
Edition Changes
08/2018 – Initial edition
02/2019 – Updates and additions to the safety instructions in accordance with
the requirements of the risk analysis.
– Formal adjustments and minor corrections of errors.
12/2019 – New warning labels for deliveries to China and to "Rest of World"
– New mains power connection
– Formal adjustments and minor corrections of errors.
