5 Tasks at the placement machine Instruction manual SIPLACE CA4 V2 5.15 Docking the component trolley in or out From software versi o n 713.0 Edition 12/2019 242 5.15 Docking the component trolley in or out 5.15.1 Safety…
Instruction manual SIPLACE CA4 V2 5 Tasks at the placement machine
From software version 713.0 Edition 12/2019 5.14 Refilling components on the changeover table
241
5.14 Refilling components on the changeover table
The Online Help contains information on refilling components with and without barcodes.
With tape feeder modules, make sure that you always splice on a new tape early enough so
that the feeder modules do not run out of components.
However, do not splice the tapes too early because if you wind the tape onto the new reel
after splicing the end of the old tape, the reel with the new tape may be overfilled. The tape
could then slip off the reel and become tangled. Under certain circumstances, this could
cause pick-up errors and prolonged down times.
5 Tasks at the placement machine Instruction manual SIPLACE CA4 V2
5.15 Docking the component trolley in or out From software version 713.0 Edition 12/2019
242
5.15 Docking the component trolley in or out
5.15.1 Safety instructions for docking component trolleys in and out
Also follow the safety instructions given in section 2.5.9, page 69.
5
In addition, the component trolley can only be docked in if the protective
covers are closed.
There is a button at each location (1,2,3 and 4). The safety concept for the component trolley
changeover specifies that the operator should push this button at the relevant placement machine
location, to dock or undock the component trolley.
WARNING
DANGER OF CRUSHING!
Risk of crushing when docking and undocking the component trolley.
Always dock/undock the component trolley alone.
When docking and undocking, make sure that there are no body limbs in the travel
area of the component trolley.
Instruction manual SIPLACE CA4 V2 5 Tasks at the placement machine
From software version 713.0 Edition 12/2019 5.15 Docking the component trolley in or out
243
5
Fig. 5.15 - 1 Safety instructions for docking the component trolley in or out
In addition, the component trolley can only be docked in if the protective
covers are closed.
(1) Button for docking and undocking the component trolley at location 1
(T) Direction of PCB conveyor
5.15.2 Docking out the component trolley
Press the button on the respective placement machine location until the component trolley is
completely undocked.
Swivel the two handles up (item 1 in fig. 5.15 - 2).
(1)
