1 Introduction Instruction manual SIPLACE CA4 V2 1.4 Operator levels From software version 713.0 Edition 12/2019 26 1.4 Operator levels Certain functions or menus m ay only be ex ecuted o r accessed b y specially trained…
Instruction manual SIPLACE CA4 V2 1 Introduction
From software version 713.0 Edition 12/2019 1.3 Qualification and training of personnel
25
1.3 Qualification and training of personnel
Personnel used for operation, preventive maintenance, inspection and installation must hold the
relevant qualifications for the job. The user must keep tight control over their responsibilities, as-
signment and supervision. Any employee who does not have the relevant training must be trained
and given appropriate instruction. The instruction is to be given by trained and authorized person-
nel.
SMT Academy
The SMT Academy provides technical training courses for your team, covering everything from
basic SIPLACE operator training to advanced follow-up training for your experts. Our courses can
either be held at your company or at one of our SIPLACE training centers worldwide. In addition
to our range of standard training programs, we can also offer customized courses to meet your
individual requirements.
SIPLACE training courses are always on a modular basis. This means that you can either book a
standard course or compile your own training program with the individual topics required for your
production environment.
1
1
Training courses for SIPLACE CA4 V2
Special operator, maintenance and technical (system configuration and repairs) training courses
are available for the SIPLACE CA4 V2.
Standard courses
– SIPLACE operator training
– SIPLACE technical training for CA4 V2
Follow-up courses and customized
courses
– SIPLACE CA4 V2 upgrade training module
– Customized training available on request
Other training courses
– SIPLACE programmer training for SIPLACE Pro
– SIPLACE Vision Training
– SIPLACE feeder care training
– SIPLACE placement heads - modular training
units
PLEASE NOTE
Operation of system only by qualified personnel
Only staff with the relevant qualifications may start up, operate or otherwise work on
the placement machine.
The qualification must be proven by means of training courses or instruction for the per-
sonnel.
1 Introduction Instruction manual SIPLACE CA4 V2
1.4 Operator levels From software version 713.0 Edition 12/2019
26
1.4 Operator levels
Certain functions or menus may only be executed or accessed by specially trained personnel. A
differentiation is made between the following operator levels:
– Production
– Advanced production
– Service (customer)
The operator levels "Advanced production" and "Service (customer)" can be password protected.
Production 1
This operator level includes those people who have been trained to operate the placement ma-
chine. These people are authorized to use any functions associated with operating the placement
machine and may access any menus needed to use the placement machine.
Advanced production 1
People with this operator level have completed special training and are authorized to perform
setup tasks e.g. creating setup configurations or determining Vision parameters etc.
Service (customer) 1
People with this operator level are specially trained technicians at the customer end, who can, for
example, define machine option settings.
Instruction manual SIPLACE CA4 V2 2 Operational safety
From software version 713.0 Edition 12/2019 2.1 Safety instructions
27
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This instruction manual contains notes that must be observed to guarantee your personal safety
and to avoid damage to equipment. These notes are highlighted by warning triangles and are in-
dicated as follows according to the level of risk:
2
2
2
2
2
DANGER
Definition
Danger, as used in this manual, means that death, severe injury or considerable damage
to equipment will occur if the danger instructions are not followed.
WARNING
Definition
Warning, as used in this instruction manual, means that death, severe injury or consid-
erable damage to equipment may occur if the warning instructions are not followed.
CAUTION
Definition
Caution, as used in this instruction manual, means that slight injury or damage to equip-
ment may occur if the caution instructions are not followed.
PLEASE NOTE
Definition
A note, as used in this instruction manual, provides information on the product or indi-
cates a part of the instruction manual that requires particular attention.
