7.4 Sensor for the component reject bin
[00116848-xx] Query component reject bin X-Series/D3
The sensor for the component reject bin monitors whether the reject bin is seated correctly in its
mount.
– If the reject bin was not inserted correctly, the placement machine cannot be started.
– If the reject bin jumps out of its mount during the placement process, the placement machine
will be stopped immediately to avoid a head crash.
Each reject bin can be monitored by a separate sensor.
7
PLEASE NOTE
When using a SIPLACE SpeedStar (C&P20 M2) at a location without SWS, we recom-
mend that you install the optional sensor for the component reject bin.
Instruction manual SIPLACE CA4 V2 7 Station extensions
From software version 713.0 Edition 12/2019 7.5 PCB barcode scanner
297
7.5 PCB barcode scanner
7.5.1 Description
The PCB barcode reader is used to automatically record and decode barcodes on boards. The
PCB barcode scanners are installed on a special frame on the input side of the placement ma-
chine on the PCB conveyor. Depending on the position of the barcode strips, the barcode scanner
can be attached in a few simple steps so that the strips can be read parallel to or across the PCB
conveyor direction.
When using dual lane conveyors, four board barcode readers can be retrofitted. These can scan
both the top or bottom of the boards on both conveyor lanes.
There are two variants of the barcode scanner:
– 2D board code reader
This code reader processes barcodes and matrix codes. Matrix code is primarily used when
there is
not enough space for barcode labels. 7
7.5.2 Technical data - 2D code reader
7
Dimensions (L x W x H) 55 mm x 42 mm x 22 mm
Weight 125 grams
Code types 2D Data Matrix ECC 0, 50, 80, 100, 140 and 200
Data Matrix ECC200
QR Code, MicroQR Code
Barcode length
Single lane conveyor
Dual lane conveyor, asynchronous
Dual lane conveyor, synchronous
Max. 40 characters
Max. 40 characters
Max. 40 characters
Data interface RS232, USB 2.0
Electrical connection 15-pin D-Sub HD connector
Operating voltage 5 V- to 24 V-
7 Station extensions Instruction manual SIPLACE CA4 V2
7.6 Input conveyor and output conveyor extensions From software version 713.0 Edition 12/2019
298
7.6 Input conveyor and output conveyor extensions
Item no. 00519971.xx Input conveyor extension for single lane conveyor
Item no. 00519972.xx Input conveyor extension for dual lane conveyor
Item no. 00519973.xx Output conveyor extension for single lane conveyor
Item no. 00519974.xx Output conveyor extension for dual lane conveyor
7.6.1 Description
The input/output conveyor extensions can be fitted as board buffers between two machines. This
involves fitting an output conveyor extension to the output conveyor of the first placement machine
in the line and an input conveyor extension to the input conveyor of the following placement ma-
chine. This intermediate space serves as a buffer to prevent any waiting time during board con-
veyor. The input/output conveyor extensions can also be fitted to the beginning and end of a line.
7
CAUTION
Improved ease of operation of SIPLACE CA4 V2 and reachability of EMERGENCY
STOP button
Make sure you fit an input conveyor extension or an output conveyor extension, if
you are placing a SIPLACE CA4 V2 with a SIPLACE X-Series in the same line.
