2.2.10 Warning signs on the SIPLACE SpeedStar C&P20 M2
2
Fig. 2.2 - 11 Warning signs on the SIPLACE SpeedStar C&P20 M2
(1) Temperature sign, item no. 03031926-01
(2) Housing for the star motor
(3) Handle
Item W laser class 2, item no. 03155298-01
(1)
(2)
(3)
W laser class 2
Instruction manual SIPLACE CA4 V2 2 Operational safety
From software version 713.0 Edition 12/2019 2.2 Warning labels
53
2.2.11 Meaning and description of warning labels
2.2.11.1 High temperatures on the SIPLACE C&P20 M2
2
1 in fig. 2.2 - 11, page 52 (quantity per SIPLACE C&P20 M2: 1)
2.2.11.2 Laser class 2 on the component sensor
2
Item W laser class 2 in fig. 2.2 - 11, page 52, item no. 03134118-01 (quantity per C&P20 P: 1)
2
High temperatures on the SIPLACE C&P20 M2 during continuous operation
Risk of burns due to high temperatures!
The housing of the star motor and the handle on the placement head may
become very hot during continuous operation and in ambient temperature in
excess of 22 °C.
Be careful when touching the parts.
2
2
2
LASER RADIATION
Laser class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
2 Operational safety Instruction manual SIPLACE CA4 V2
2.2 Warning labels From software version 713.0 Edition 12/2019
54
2.2.12 Warning signs on the SIPLACE MultiStar CPP M
2
Fig. 2.2 - 12 Warning signs on the SIPLACE MultiStar CPP M
(1) Temperature sign, item no. 03031926-01
Item W laser class 2, item no. 03155298-01
(1)
W laser class 2
