Instruction manual SIPLACE CA4 V2 2 Operational safety
From software version 713.0 Edition 12/2019 2.5 Safety instructions for operation
67
2.5.7 Safety instructions for using the nozzle changer
Observe the following instructions to avoid risk of collision between the placement head and the
nozzle changer.
2
2
WARNING
Risk of head crashes with mixed configurations!
There is a risk of head crashes with mixed configurations.
Only install the corresponding nozzle changer for each placement head, with the
nozzle magazines for the respective placement head.
WARNING
Risk of head crashes with protruding lever!
A lever which projects above the magazine could lead to a placement head crash.
You should therefore make sure that the lever does not protrude over the maga-
zines.
2 Operational safety Instruction manual SIPLACE CA4 V2
2.5 Safety instructions for operation From software version 713.0 Edition 12/2019
68
2.5.8 High temperatures on the X feeder modules during continuous operation
2
Fig. 2.5 - 3 High temperatures on the X feeder modules during continuous operation
(1) Temperature sign, item no. 03031926-01
(2) Stepping motor
2
2
CAUTION
Risk of burns due to high temperatures!
The stepping motors can become very hot during continuous operation and in an ambient
temperature in excess of 22 °C.
Be careful when touching the motors.
(1)
(2)
(2)
Instruction manual SIPLACE CA4 V2 2 Operational safety
From software version 713.0 Edition 12/2019 2.5 Safety instructions for operation
69
2.5.9 Safety instructions for docking the component trolley in or out
2
2
2
2
2
2.5.10 Safety instructions for emptying the waste tape container
The waste tape container must be pulled out of the component trolley for emptying. There is a risk
of catching your thumbs as you do so. To prevent this, observe the safety instructions in section
5.8.2
, page 221.
WARNING
Operation only with component trolley!
The placement machine may only be operated if there is a component trolley present
and docked at each location.
Fill any free locations with dummy feeder modules as described in
section 2.6.5
, page 83.
WARNING
DANGER OF CRUSHING!
Risk of crushing when docking and undocking the component trolley.
Always dock/undock the component trolley alone.
CAUTION
Risk of breaking handles!
Risk of breaking handles when transporting the component trolley.
When transporting the component trolley, do not lift it by its handles.
CAUTION
Risk of injuring limbs!
Risk of injuring limbs when docking and undocking.
When docking and undocking, make sure that there are no body limbs in the travel
area of the component trolley.
CAUTION
Risk of injury due to uncontrolled movement of component trolley!
Make sure that the component trolley does not roll away on inclined surfaces or ramps.
Secure the component trolley so that it does not start rolling away.
