<STX> Acme Logic Design Jane Engineer Feb. 29 1983 Widget Decode 756-AB-3456 Rev C Device Mullard 12AX7* L0000 1111111011 1111111111 1111000000 0000000000 0000000000 0000000000 0000000000 0000000000 0000000000 0000…

V0001C01010101NHLLLHHLHLN*

V0002C01011111NHLLHLLLHLN*

V0003C10010111NZZZZZZZZZN*

V0004C01010100NFLHHLFFLLN*

<STX>

Acme Logic Design Jane Engineer Feb. 29 1983

Widget Decode 756-AB-3456 Rev C Device Mullard 12AX7*

L0000 1111111011 1111111111 1111000000 0000000000

0000000000 0000000000 0000000000 0000000000

0000000000 0000000101 1111111111 1111111111

0000000000 0000000000 0000111101 1111111111

1111111111 1111110111 1111111111 1111111111*

L0200 1110101111 1111110000 0000000000 0000000000

1111111111 1111011011 1111111111 1111111110

0111111111 1111111111 1111111110 1111111111

1111111111 1111101111 1111111111 1111101111

0000000000 0000000000 0000*

<EXT>0000

0091-2

%1561C310020202020202

SUMCHECK: 1CH = 1+5+6+3+1+0+0+0+2+0+2+...

OBJECT CODE: 6 BYTES

LOAD ADDRESS: 100 H

BLOCK TYPE: 6 (DATA)

HEADER CHARACTER

BLOCK LENGTH: 15H = 21

0092-2
