199-2100 Chapt er 6 Product Change Menu This chapter describes how to navigate in each window of “Product Change Menu”. 1. Outline of Product Change Menu 2. Setup 3. “PP CHANGE” Window 4. “SPRT -PINS” Window 5. “NOZ.CHG.…
EUKYX
5-12199-2100
6.2 "RECOG IMAGE" Confirmation Window
[6] File Name
The file names where recognized images have been saved automatically, are displayed.
The name to be saved is added to the file name. Therefore, using the file name, the recognition
processing contents can be checked.
File Name Example
◻◻◻
••••
.hdb
Saving object name
Saving object Saving object name
Component Recognition DA_
PEC Recognition MA_
Basis Mark Recognition KA_
Component Recognition Test DT_
PEC Recognition Test MT_
Stocker Nozzle Check NE_
Nozzle ID Recognition NO_
Bad Mark Recognition (Option) BM_
Bad Mark Recognition Test (Option) BT_
2-D Barcode Recognition (Option) BC_
2-D Barcode Recognition Test (Option) BE_
Nozzle Recognition TN_
Camera Magnification Teaching TC_
Basis Mark Teaching TB_
Lighting Teaching TL_
PEC Recognition Camera & Beam OFFset TM_
Feeder OFFset TF_
Nozzle Stocker OFFset TS_
Traverse Drawer Position OFFset (Option) TT_
Feeder Pocket Recognition TP_
Camera OFFset TA _
Head Rotational Center, Basis Mark Position TH_
Head Rotational Axis OFFset TR_
Coplanarity Check Unit OFFset (Option) TO_
199-2100
Chapter 6
Product Change Menu
This chapter describes how to navigate in each window of “Product
Change Menu”.
1. Outline of Product Change Menu
2. Setup
3. “PP CHANGE” Window
4. “SPRT-PINS” Window
5. “NOZ.CHG.” Window
6. “PCB XFER” Window
7. “Test&Tch” Submenu
8. “PCB.CNT.” Window
EUKYX
EUKYX
6-1199-2100
1. Outline of Product Change Menu
1. Outline of Product Change Menu
The following shows the hierarchical structure of the menus (including the submenus and windows)
for the setup operations.
Setup
Reference
Item Nos.
"PP CHANGE" Window
3
"CNVR Set-up" Window
4
"NOZ.CHG." Window
5
"PCB XFER" Window
6
"Test&Tch" Submenu
7
"PCB.CNT." Window
8
F2F1
