Change over table insert X4 S
Page 7 / 12 24.11.2021
Change over table insert X4 S
Page 8 / 12 24.11.2021
Change over table insert X4 S
Page 9 / 12 24.11.2021
Pos. Item no. Description Part marking
1 03098442S02 CO TROLLEY INSERT SX4 VARIO SPARE PART
2 03066692-02 COT DOCKING UNIT, X-SERIES
3 03066707-02 FRAME
4 03012875-03 SIDE PANEL, RIGHT-H. SIDE,
MACHINED
5 03012823-01 SLOTTED RAIL SPARE PART
6 03042507-01 ISO 4762 - M 4 X 16-A2-70 STANDARD PARTS
7 03040555-02 RAISING MECHANICS ON THE LEFT.
8 03004118-02 CAM DISK
03038300-01 INTERFLON GREASE MP 2/3 Consumable
10 03040556-02 LIFTING MECHANISM, RIGHT SPARE PART
11 03004118-02 CAM DISK
03038300-01 INTERFLON GREASE MP 2/3 Consumable
13 03059462-01 SEPARATING LAYER
14 03059438-01 ADAPTER PLATE
15 03027548-01 GUIDE, LEFT-HAND SIDE SPARE PART
16 03026031-01 GUIDE, RIGHT-HAND SIDE SPARE PART
17 03004112-01 CYLINDER COVER, LEFT-HAND SIDE
18 03004114-01 CYLINDER COVER, RIGHT-HAND
SIDE
SPARE PART
19 03009853-01 CENTERING PIN, ROUND SPARE PART
20 03045200-01 DIN EN ISO 7380-M4 X 6-A2-70 STANDARD PARTS
21 03047616-01 CYLINDER 50X60 SA-207074 SPARE PART
22 03002876-01 SHORT STROKE ZYLINDER 20X10 SPARE PART
23 03090819-01 VALVE WITH CHOKE
GRLA-1/8-QS-4RS-D
24 03011582-02 FEEDER UNLOCK DEVICE 40-WAY SPARE PART
25 03067460-01 WASTE SLIDE WELDED COMPLETE SPARE PART
26 03039243-01 EXTENSION SPARE PART
27 03009344-01 WARNING LABEL NO. 205
00346434S01 EDGE PROTECTION TYPE 4610026
(HAPPICH)
CONSUMABLE
29 03089040-01 WARNING DECAL WASTE CHUTE
COT40
30 03052576-02 USED TAPE CHANNEL SPARE PART
31 00318355-01 DIN 7991-M4 X 10-A2
