1 Introduction
1.2 Important Notes about this Manual
User Manual SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019 9
1.1.7 Electromagnetic compatibility (EMC)
All SIPLACE products are designed and tested for professional use in industrial applications.
Electromagnetic compatibility in terms of the emission of interference cannot be guaranteed in any
other environment.
1.1.8 Use of original accessories and spare parts
Only use original spare parts and authorized accessories. The use of other parts will affect safety
and will invalidate the liability for any consequential damage.
1.2 Important Notes about this Manual
1.2.1 Contents and Filing of this Manual
This User Manual contains basic information that must be observed when setting up, operating and
maintaining the machine. The service engineers, qualified staff, operators and users must therefore
read it before commencing installation and commissioning. The instructions must be kept perman-
ently accessible wherever the machine is used.
In addition, the user must ensure that the employees have fully understood the contents of the user
manual.
1.2.2 Danger notes
WARNING
Danger notes
► Work may only be performed on the JEDEC tray feeder if the personnel concerned
have a thorough knowledge of the relevant section of the user manual.
► All work must be carried out by appropriately trained and qualified personnel.
► All warnings, cautions and hazard notes must be observed.
► Carefully read through Chapter 2 on operational safety in the user manual for this pur-
pose.
1.2.3 Manufacturer's/supplier's liability
We draw your attention to the fact that these instructions only contain descriptive and explanatory
material and do not include any contractual conditions or undertakings. All obligations of ASM
Assembly Systems GmbH & Co. KG are conclusively specified in the respective contract, on the
basis of which you have received the machine described therein. This applies in particular to all
statements regarding performance or service life and the agreed liability for faults or defects. The
provisions of the contract regarding the liability for faults or defect are neither extended nor restric-
ted by any statements in this manual.
1 Introduction
1.2 Important Notes about this Manual
10 User Manual SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019
1.2.4 Release History
Document
SIPLACE TX V1/V2 Series
JEDEC Tray Feeder (JTF-ML2)
User Manual
Release Amendments
06/2017 Initial release
12/2018 Adding machine type SIPLACE TX V2 to the scope of the document.
11/2019 Addition/Update of the following subjects:
●
Risk of crashing when using thick JEDEC trays
●
Prerequisites and restrictions
(new head types for SIPLACE TX V2)
●
Scope of delivery SIPLACE TX V1 updated (cable: Power Adapter JTF
[03160347‑xx])
●
Establishing the electrical connections on the SIPLACE TX-Series V2 (up-
dated)
●
Magnets with reduced height for Cookie Trays
●
Magnets with reduced height [03160331‑xx] for use with magazine sheets
(Cookie Trays))
●
Appendix (FCU added)
1.2.5 Further Information and Contents of Documentation Pack
1.2.5.1 How To Get Information
If you have any questions about this manual or if you would like more information about certain
subjects, please contact your local SIPLACE branch or us directly:
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Str. 44
81379 München
1.2.5.2 SIPLACE on the World Wide Web (WWW)
Log in to our SIPLACE® homepage at http://www.asm-smt.com.
You can choose between the German and English version.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the MySIPLACE user group. Here you can call
up special information about our placement systems, e.g.
●
technical documentation
●
technical information
●
spare parts lists etc.
Registration for the MySIPLACE user group is very simple:
► At the head of the web site, click on
and then on the Register
link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with user name and password.
1 Introduction
1.2 Important Notes about this Manual
User Manual SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019 11
1.2.6 Abbreviations
Abbreviation Description
CO Component
COT Changeover table
COTi Changeover table insert
CPP Collect&Pick&Place head
ESD Electrostatic sensitive device
JTF JEDEC tray feeder
PCB Printed circuit board
P&P Pick&Place
TH TwinHead
