3- 2 Mx Se ries M anual CHECK EVERY 1500 HOURS (季 检 ) ...................................... 3-38 LEAD SCREW /LINEAR SLIDE CHECK ................................... 3-38 ANC CHECK ........................................…
维护及检验方法
目 录
REGULAR CHECK ITEMS FOR EACH PERIOD (项目及周期) ................... 3-3
REGULAR CHECK ITEMS FOR EACH UNIT (各部位检验周期) ................. 3-4
REGULAR CHECK ITEMS FOR GREASING (注油项目及周期) .................. 3-5
CHECK EVERY 24 HOURS (日检) ........................................ 3-6
检验气压(运行前) ................................................. 3-6
CLEANING THE LINEAR MOTOR STATOR (运行前) ........................ 3-7
检验装备内部 (运行前) ............................................ 3-8
检查异常噪音(运行后) ............................................. 3-9
CHECK EVERY 150 HOURS (周检) ...................................... 3-10
CAMERA LENS 및 LENS COVER........................................ 3-10
NOZZLE CHECK .................................................... 3-12
CHECKING THE BLOWING LEVEL VALUE AT THE NOZZLE TIP .............. 3-15
CHECKING THE VACUUM PRESSURE AT THE NOZZLE TIP .................. 3-16
可用于各个配件的 NOZZLE .......................................... 3-17
CHECK EVERY 500 HOURS (月检) ...................................... 3-23
LINEAR SCALE CHECK .............................................. 3-23
LINEAR SLIDE CHECK .............................................. 3-25
Z 轴 NOZZLE SHAFT MOVING CHECK ................................... 3-28
Z 轴 RACK & PINION CHECK ......................................... 3-29
R 轴 BEARING CHECK ............................................... 3-31
TIMING BELT AND PULLEY CHECK .................................... 3-33
Z 轴 LINEAR SLIDE CHECK .......................................... 3-34
AIR FILTER CHECK ................................................ 3-35
CASTING OFF NG PART CHECK ....................................... 3-37
CHAPTER
3-
2
Mx Series Manual
CHECK EVERY 1500 HOURS (季检) ...................................... 3-38
LEAD SCREW /LINEAR SLIDE CHECK ................................... 3-38
ANC CHECK ........................................................ 3-40
TIMING BELT CHECK ................................................ 3-43
TIMING BELT TENSION CHECK ........................................ 3-44
CHECK EVERY 3000 HOURS (半年检) .................................... 3-45
裸露钢部表面处理 CHECK ........................................... 3-45
BOARD TRANSFER BELT(RING BELT) CHECK ............................. 3-46
第3章 维修及检验方法
3-3
Regular Check Items for Each Period
(项目及周期)
Period Item Checking Point Module Ref
检验气压(运行前)
1. Main Air
2. Head的吹压(Blow)
3. Head的吸压(Sucktion)
Cover 3-6
Linear Motor Stator (运行前) 检验定子部磁铁之间有无异物 Conveyor 3-7
检验装备内部(运行前) 检验驱动部异物 Conveyor 3-8
24H
(每天)
检查异常噪音(运行后)
X、Y轴Linear Slide部和Conveyor部有
无异常噪音/震动
X-Y Gantry
Conveyor
3-9
Camera Lens Camera表面清洁及检验 Vision 3-10
Nozzle Check(检验喷嘴) 防止异物进入工作环境 Head 3-12
150H
(每周)
Fan-filter Check 检验Fan-filter清洁状态 Cover -
Linear Scale Check 检验 Linear Scale 异物 X-Y Gantry 3-23
Linear Slide Check 周期性清扫及注油 X-Y Gantry 3-25
Z轴 Nozzle Shaft Moving Check 检验Spline的磨损，Shaft的弯曲 Head 3-28
Z轴 Rack & Pinion check 检验注油及间隔 Head 3-29
R轴 Bearing check 检验Bearing与Bush的磨损 Head 3-31
Timing Belt and Pulley check 检验Timing Belt与Pulley的磨损 Conveyor
3-33
Z轴 Linear Slide 周期性清扫及注油 Head 3-34
Air Filter Check(空气滤清器) 打开排污阀 Cover 3-35
500H
(每月)
Casting Off NG Part 周期性扫除 Conveyor 3-37
Lead Screw/Linear Slide 周期性扫除及注油 Conveyor 3-38
ANC(自动换嘴装置) 检验 Sensor附着状态 ANC 3-40
Timing Belt(同步皮带) 检验磨损及受损 Conveyor 3-43
1500H
(3个月)
Timing Belt Tension(同步皮带张力) 适当调整Tension Conveyor 3-44
裸露钢部表面处理 检验裸露部位有无发青 X-Y Gantry 3-45 3000H
(6个月)
Board Transfer Belt(Ring Belt) 检验Ring Belt磨损及受损 Conveyor 3-46
