Appendix E - 7 Draf t ( ) Check ( ) Approval ( Mx100&200_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion Conveyor Step Motor Part & SEMEMA Examiner Module No : 02 Address : A Rev : 0 Revised date: 2007 /…
E-6 Mx Series Manual
Draft( ) Check ( ) Approval( )
Mx100&200_NX12 I/O Check Sheet
Serial NO Date
Signee
Description
Lamp&Switch & Key Part
Examiner
Module No : 01 Address : 9 Rev : 0 Revised date : 2007 / 11/ 24
Name Label I/O Port Description Check Remark
O_BUZZER 1 0 Buzzer OK / NG
O_REDLAMP 1 1 System Fault Lamp (Red) OK / NG
O_GRNLAMP 1 2 System Running Lamp (Green) OK / NG
O_YELLAMP
System Lamp
1 3 System Error Lamp (Yellow) OK / NG
OT0104 0 4 OutletConv. Start/Stop Switch OK / NG OPTION
SN0105 1 5 OutletConv. EndPosion Sensor OK / NG OPTION
I_F_FEEDERKEY 0 6 f Feeder Key Input OK / NG
O_F_FEEDERPKEY
f_FEEDER
KEY
1 7 f Feeder Key LED Output OK / NG
O_F_FEEDERP OT0108 1 8 f Feeder Control Output(To=>SSR1) OK / NG
I_R_FEEDERKEY 0 9 r Feeder Key Input OK / NG
O_R_FEEDERPKEY
r_FEEDER
KEY
1 10 r Feeder Key LED Output OK / NG
O_R_FEEDERP OT0111 1 11 r Feeder Control Output(To=>SSR2) OK / NG
I_STOPKEY 0 12 f/r STOP Key Input OK / NG
O_STOPKEY
STOP KEY
1 13 f/r STOP Key LED Output OK / NG
I_FDOORLOCK,
I_RDOORLOCK
0 14 f/r DOOR Key Input OK / NG
O_FOX_DOOR_LOCK
DOOR KEY
1 15 f/r DOOR Key LED Output OK / NG
Notice:
1, I/O => Input = 0
Output = 1
2.Port 4,5
번
Part
회수용
OutletConveyor .(OPTION)
Appendix E-7
Draft
(
)
Check
( )
Approval
(
Mx100&200_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 02 Address : A Rev : 0 Revised date: 2007 / 11/ 24
Name Label I/O Port Description Check Remark
O_CHBEL1STA 1 0 Work Ent Conv_Belt Start Output OK / NG
O_CHBEL1LOW 1 1 Work Ent Conv_Belt Low Speed Output OK / NG
O_CHBEL1MID 1 2 Work Ent Conv_Belt Middle Speed Output OK / NG
O_CHBEL1DIR 1 3 Work Ent Conv_ Belt Reverse Output OK / NG
O_CHBEL2STA 1 4 Work Conv_ Belt Start Output OK / NG
O_CHBEL2LOW 1 5 Work Conv_ Belt Low Speed Output OK / NG
O_CHBEL2MID 1 6 Work Conv_ Belt Middle Speed Output OK / NG
O_CHBEL2DIR 1 7 Work Conv_ Belt Reverse Output OK / NG
O_CHBEL3STA 1 8 Work Ext Conv_ Belt Start Output OK / NG
O_CHBEL3LOW 1 9 Work Ext Conv_Belt Low Speed Output OK / NG
O_CHBEL3MID 1 10 Work Ext Conv_Belt Middle Speed Output OK / NG
O_CHBEL3DIR
TB CN1
1 11 Work Ext Conv_ Belt Reverse Output OK / NG
I_FNEXTIN 0 12 Next System Input Signal OK / NG
I_FPREVIN 0 13 Previous System Input Signal OK / NG
O_FNEXTOUT 1 14 Next System Output Signal OK / NG
O_FPREVOUT
TB CN10
1 15 Previous System Output Signal OK / NG
Notice :
1, I/O => Input = 0
Output = 1
E-8 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Mx100&200_NX12 I/O Check Sheet
Serial NO Date Singee
Description
LSM&SVEN Part
Examiner
Module No : 03 Address : B Rev : 0 Revised date : 2007 / 11/ 24
Name Label I/O Port Description Check Remark
I_F_XLMTEMP 0 0 Linear Motor Temp Signal #01 OK / NG
I_F_Y1LMTEMP 0 1 Linear Motor Temp Signal #02 OK / NG
I_F_Y2LMTEMP
C/B CN2
0 2 Linear Motor Temp Signal #03 OK / NG
I_F_DOOR_LOCK SN0303 0 3 f Door Sensor OK / NG
O_F_DOOR_LOCK 1 4 f Door Locking Signal OK / NG
F_DOOR S/W
Sig
0 5 f Door System Sensor OK / NG
I_R_DOOR_LOCK SN0306 0 6 r Door Sensor OK / NG
O_R_DOOR_LOCK 1 7 r Door Locking Signal OK / NG
R_DOOR S/W
Sig
0 8 r Door System Sensor OK / NG
O_BULLAMP OT0309 1 9 System Runing Lamp OK / NG
SN0310 0 10 f_Floating Sensor OK / NG
SN0311 0 11 r_Floating Sensor OK / NG
O_LAMP OT0312 1 12 Machine LAMP On/Off OK / NG
I_AIRLOW SN0313 0 13 Air Pressure Low Sensor OK / NG
O_SVEN P-BOX P1 1 14 SVEN (Servo Voltage Enable) OK / NG
I_EMERGENCY
EMG
S/W(N.O)
0 15 Machine Emergency S/W Input OK / NG
Notice:
1, I/O => Input = 0
Output = 1
