E-10 Mx Series Manual Draft ( ) Check ( ) Approval ( Mx100&200_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion Front Trolley Part Examiner Module No : 05 Address : D Rev : 0 Revised date : 2007 /10/ 04 Name …
Appendix E-9
Draft
(
)
Check
( )
Approval
(
Mx100&200_NX12 I/O Check Sheet
Serial NO Date Signee
Description
ANC Part
Examiner
Module No : 04 Address : C Rev : 0 Revised date : 2007 / 11/28
Name Label I/O Port Description Check Remark
I_F_ANC_UNLOCK SN0400 0 0 f ANC Unlock Sensor OK / NG
I_F_ANC_LOCK SN0401 0 1 f ANC Lock Sensor OK / NG
I_F_ANC_UP SN0402 0 2 f ANC Up Sensor OK / NG P-ANC
I_F_ANC_DOWN SN0403 0 3 f ANC Down Sensor OK / NG P-ANC
O_F_ANC_UNLOCK SL0404 1 4 f ANC Lock/Unlock Solenoid Valve OK / NG
O_F_NBASE_UP SL0405 1 5 f ANC Up/Dn Solenoid Valve OK / NG P-ANC
I_R_ANC_UNLOCK SN0406 0 6 r ANC Unlock Sensor OK / NG
I_R_ANC_LOCK SN0407 0 7 r ANC Lock Sensor OK / NG
I_R_ANC_UP SN0408 0 8 r ANC Up Sensor OK / NG P-ANC
I_R_ANC_DOWN SN0409 0 9 r ANC Down Sensor OK / NG P-ANC
O_R_ANC_UNLOCK SL0410 1 10 r ANC Lock/Unlock Solenoid Valve OK / NG
O_R_NBASE_UP SL0411 1 11 r ANC Up/Dn Solenoid Valve OK / NG P-ANC
O_CHBEL STA 1 12 Outlet Conv_Belt Start Output OK / NG OPTION
O_CHBEL LOW 0 13 Outlet Conv_Belt Low Speed Output OK / NG OPTION
O_CHBEL MID 0 14 Outlet Conv_Belt Middle Speed Output OK / NG OPTION
O_CHBEL DIR
CB CN 2
0 15 Outlet Conv_ Belt Reverse Output OK / NG OPTION
Notice :
1, I/O => Input = 0
Output = 1
2.12~15 Collectible Port Part Outlet Conveyor(OPTION)
E-10 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Mx100&200_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Front Trolley Part
Examiner
Module No : 05 Address : D Rev : 0 Revised date : 2007 /10/ 04
Name Label I/O Port Description Check Remark
SN0500 0 0 f Trolley Feeder Base Down Sensor OK / NG
SPARE0501 1 OK / NG
SN0502 0 2 f Trolley Feeder Base Set Position S/W(Left) OK / NG
SN0503 0 3 f Trolley Feeder Base Set Position S/W(Right) OK / NG
SN0504 0 4 f Trolley Connector Block Up Sensor OK / NG
Spare0505 5 spare OK / NG
SN0506 0 6 f Trolley Feeder Base In Position Sensor(Left) OK / NG
SN0507 0 7 f Trolley Feeder Base In Position Sensor(Right) OK / NG
SL0508 1 8 f Trolley Feeder Base UP Sol Valve OK / NG
SL0509 1 9 f Trolley Connector Block UP Sol Valve OK / NG
SN0510 0 10 OK / NG Not Applied
SN0511 0 11 OK / NG Not Applied
SN0512 1 12 OK / NG Not Applied
SN0513 1 13 OK / NG Not Applied
SL0514 1 14 f Trolley Feeder Base DN Sol Valve OK / NG
SL0515 1 15 f Trolley Connector Block DN Sol Valve OK / NG
Notice :
1, I/O => Input = 0
Output =
Appendix E-11
MODULE NO. DESCRIPTION(Mx400) Remark
00 F_Conveyor Sensor &ANC Solenoide Part
01 R_Conveyor Sensor & Solenoide Part
02 ANC&Door Sensor Part
03 Lamp&Switch&Key Part
NXO2V B/D COMM 0
10 F_Conveyor Step Motor Part & SEMA
11 R_Conveyor Step Motor Part & SEMA
12 Switch&Key Part
NXO2V B/D COMM 1
20 Front Trolley(Option)
21 Rear Trolley(Option)
NXO2V B/D COMM 2
