Appendix E - 1 1 MODULE NO. DESCRIPTION(Mx 400) Remark 00 F_Conveyor Sensor &ANC Solenoide Part 01 R_Conveyor Sensor & Solenoide Part 02 ANC&Door Sensor Part 03 Lamp&Switch&Key Part NXO2V B/D COMM 0 1…
E-10 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Mx100&200_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Front Trolley Part
Examiner
Module No : 05 Address : D Rev : 0 Revised date : 2007 /10/ 04
Name Label I/O Port Description Check Remark
SN0500 0 0 f Trolley Feeder Base Down Sensor OK / NG
SPARE0501 1 OK / NG
SN0502 0 2 f Trolley Feeder Base Set Position S/W(Left) OK / NG
SN0503 0 3 f Trolley Feeder Base Set Position S/W(Right) OK / NG
SN0504 0 4 f Trolley Connector Block Up Sensor OK / NG
Spare0505 5 spare OK / NG
SN0506 0 6 f Trolley Feeder Base In Position Sensor(Left) OK / NG
SN0507 0 7 f Trolley Feeder Base In Position Sensor(Right) OK / NG
SL0508 1 8 f Trolley Feeder Base UP Sol Valve OK / NG
SL0509 1 9 f Trolley Connector Block UP Sol Valve OK / NG
SN0510 0 10 OK / NG Not Applied
SN0511 0 11 OK / NG Not Applied
SN0512 1 12 OK / NG Not Applied
SN0513 1 13 OK / NG Not Applied
SL0514 1 14 f Trolley Feeder Base DN Sol Valve OK / NG
SL0515 1 15 f Trolley Connector Block DN Sol Valve OK / NG
Notice :
1, I/O => Input = 0
Output =
Appendix E-11
MODULE NO. DESCRIPTION(Mx400) Remark
00 F_Conveyor Sensor &ANC Solenoide Part
01 R_Conveyor Sensor & Solenoide Part
02 ANC&Door Sensor Part
03 Lamp&Switch&Key Part
NXO2V B/D COMM 0
10 F_Conveyor Step Motor Part & SEMA
11 R_Conveyor Step Motor Part & SEMA
12 Switch&Key Part
NXO2V B/D COMM 1
20 Front Trolley(Option)
21 Rear Trolley(Option)
NXO2V B/D COMM 2
E-12 Mx Series Manual
Draft
( )
Check
( )
Approval
(
Mx400 NX12 I/O Check Sheet
Serial NO Date Signee
Description
F Conveyor Sensor&ANC Solenoide Part
Examiner
Module No : 00 Address : 8 Rev : 0 Revised date : 2007 / 09/ 14
Name Lable I/O Port Description Check Remark
I_F_ENTRY_ENT SN0000 0 0 Front Conv PCB Entrance Sensor OK / NG
I_F_ENTRY_WAIT SN0001 0 1 f Conv Entrance Wait Sensor OK / NG
I_F_WORK1_SET SN0002 0 2 f Work Conv 1
ST
Set Position Sensor OK / NG
I_F_WORK1_STOP SN0003 0 3 f Work Conv 1
ST
Main Stopper Up Sensor OK / NG
I_F_WORK2_SET SN0004 0 4 f Work Conv 2
ST
Set Position Sensor OK / NG Large PCB
I_F_WORK2_STOP SN0005 0 5 f Work Conv 2
ST
Main Stopper Up Sensor OK / NG Large PCB
I_F_WORK_PHUP SN0006 0 6 f Work Conv_Push Plate Up Sensor OK / NG
I_F_WORK_PHDN SN0007 0 7 f Work Conv_Push Plate Down Sensor OK / NG
SN0008 0 8 OK / NG
O_F_WORK_PHUP SL0009 1 9 f Work Conv_Push Plate Up Solenoid Valve OK / NG
O_F_WORK_PHDN SL0010 1 10 f Work Conv_Push Plate Down Solenoid Valve OK / NG
O_F_WORK1_STOP SL0011 1 11 f Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG
O_F_WORK2_STOP SL0012 1 12 f Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG
O_F_WORK_EDGE SN0013 1 13 Outlet Conveyor EXT Sensor OK / NG
O_F_ANC_UNLOCK SL0014 1 14 f ANC Lock/Unlock Solenoid Valve OK / NG
O_F_NBASE_UP SL0015 1 15 f ANC Up/Dn Solenoid Valve OK / NG P-ANC
Note:
1, I/O => Input = 0
Output = 1
In case of applying 2.Port 0 Inlet Conveyor, Proceed with Inlet Conv PCB Entrance Sensor
In case of applying 3.Port 8 Outlet Conveyor, Proceed with Outlet Conv PCB Exit Sensor
