E-12 Mx Series Manual Draft ( ) Check ( ) Approval ( Mx400 NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion F Conveyor Sensor&ANC Solenoide Part Examiner Module No : 00 Address : 8 Rev : 0 Revised date : 2007…
Appendix E-11
MODULE NO. DESCRIPTION(Mx400) Remark
00 F_Conveyor Sensor &ANC Solenoide Part
01 R_Conveyor Sensor & Solenoide Part
02 ANC&Door Sensor Part
03 Lamp&Switch&Key Part
NXO2V B/D COMM 0
10 F_Conveyor Step Motor Part & SEMA
11 R_Conveyor Step Motor Part & SEMA
12 Switch&Key Part
NXO2V B/D COMM 1
20 Front Trolley(Option)
21 Rear Trolley(Option)
NXO2V B/D COMM 2
E-12 Mx Series Manual
Draft
( )
Check
( )
Approval
(
Mx400 NX12 I/O Check Sheet
Serial NO Date Signee
Description
F Conveyor Sensor&ANC Solenoide Part
Examiner
Module No : 00 Address : 8 Rev : 0 Revised date : 2007 / 09/ 14
Name Lable I/O Port Description Check Remark
I_F_ENTRY_ENT SN0000 0 0 Front Conv PCB Entrance Sensor OK / NG
I_F_ENTRY_WAIT SN0001 0 1 f Conv Entrance Wait Sensor OK / NG
I_F_WORK1_SET SN0002 0 2 f Work Conv 1
ST
Set Position Sensor OK / NG
I_F_WORK1_STOP SN0003 0 3 f Work Conv 1
ST
Main Stopper Up Sensor OK / NG
I_F_WORK2_SET SN0004 0 4 f Work Conv 2
ST
Set Position Sensor OK / NG Large PCB
I_F_WORK2_STOP SN0005 0 5 f Work Conv 2
ST
Main Stopper Up Sensor OK / NG Large PCB
I_F_WORK_PHUP SN0006 0 6 f Work Conv_Push Plate Up Sensor OK / NG
I_F_WORK_PHDN SN0007 0 7 f Work Conv_Push Plate Down Sensor OK / NG
SN0008 0 8 OK / NG
O_F_WORK_PHUP SL0009 1 9 f Work Conv_Push Plate Up Solenoid Valve OK / NG
O_F_WORK_PHDN SL0010 1 10 f Work Conv_Push Plate Down Solenoid Valve OK / NG
O_F_WORK1_STOP SL0011 1 11 f Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG
O_F_WORK2_STOP SL0012 1 12 f Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG
O_F_WORK_EDGE SN0013 1 13 Outlet Conveyor EXT Sensor OK / NG
O_F_ANC_UNLOCK SL0014 1 14 f ANC Lock/Unlock Solenoid Valve OK / NG
O_F_NBASE_UP SL0015 1 15 f ANC Up/Dn Solenoid Valve OK / NG P-ANC
Note:
1, I/O => Input = 0
Output = 1
In case of applying 2.Port 0 Inlet Conveyor, Proceed with Inlet Conv PCB Entrance Sensor
In case of applying 3.Port 8 Outlet Conveyor, Proceed with Outlet Conv PCB Exit Sensor
Appendix E-13
Draft
(
)
Check
( )
Approval
(
Mx400_ NX12 I/O Check Sheet
Serial NO Date Signee
Description
R Conveyor Sensor & Solenoid Part
Examiner
Module No : 01 Address : 9 Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check Remark
SN0100 0 0 OK / NG D-CONV
I_R_ENTRY_WAIT SN0101 0 1 r Conv Entrance Wait Sensor OK / NG D-CONV
I_R_WORK1_SET SN0102 0 2 r Work Conv 1
ST
Set Position Sensor OK / NG D-CONV
I_R_WORK1_STOP SN0103 0 3 r Work Conv 1
ST
Main Stopper Up Sensor OK / NG D-CONV
I_R_WORK2_SET SN0104 0 4 r Work Conv 2
ST
Set Position Sensor OK / NG D-CONV
I_R_WORK2_STOP SN0105 0 5 r Work Conv 2
ST
Main Stopper Up Sensor OK / NG D-CONV
I_R_WORK_PHUP SN0106 0 6 r Work Conv_Push Plate Up Sensor OK / NG D-CONV
I_R_WORK_PHDN SN0107 0 7 r Work Conv_Push Plate Down Sensor OK / NG D-CONV
SN0108 0 8 OK / NG D-CONV
O_R_WORK_PHUP SL0109 1 9 r Work Conv_Push Plate Up Solenoid Valve OK / NG D-CONV
O_R_WORK_PHDN SL0110 1 10 r Work Conv_Push Plate Down Solenoid Valve OK / NG D-CONV
O_R_WORK1_STOP SL0111 1 11 r Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG D-CONV
O_R_WORK2_STOP SL0112 1 12 r Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG D-CONV
SL0113 1 13 OK / NG D-CONV
SL0114 1 14 Inlet Stopper Up/Dn Solenoide Valve OK / NG Inlet Conv
SN0115 0 15 OK / NG
Notice :
1, I/O => Input = 0
Output = 1
2.D-CONV:Dual Conveyor
3.Port 12:Inlet Conveyor Stopper SOL
