E-14 Mx Series Manual Draft ( ) Check ( ) Approval ( Mx400_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion ANC&DOOR Sensor Part Examiner Module No : 02 Address : A Rev : 0 Revised date : 2007 / 09/ 14 Name L…
Appendix E-13
Draft
(
)
Check
( )
Approval
(
Mx400_ NX12 I/O Check Sheet
Serial NO Date Signee
Description
R Conveyor Sensor & Solenoid Part
Examiner
Module No : 01 Address : 9 Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check Remark
SN0100 0 0 OK / NG D-CONV
I_R_ENTRY_WAIT SN0101 0 1 r Conv Entrance Wait Sensor OK / NG D-CONV
I_R_WORK1_SET SN0102 0 2 r Work Conv 1
ST
Set Position Sensor OK / NG D-CONV
I_R_WORK1_STOP SN0103 0 3 r Work Conv 1
ST
Main Stopper Up Sensor OK / NG D-CONV
I_R_WORK2_SET SN0104 0 4 r Work Conv 2
ST
Set Position Sensor OK / NG D-CONV
I_R_WORK2_STOP SN0105 0 5 r Work Conv 2
ST
Main Stopper Up Sensor OK / NG D-CONV
I_R_WORK_PHUP SN0106 0 6 r Work Conv_Push Plate Up Sensor OK / NG D-CONV
I_R_WORK_PHDN SN0107 0 7 r Work Conv_Push Plate Down Sensor OK / NG D-CONV
SN0108 0 8 OK / NG D-CONV
O_R_WORK_PHUP SL0109 1 9 r Work Conv_Push Plate Up Solenoid Valve OK / NG D-CONV
O_R_WORK_PHDN SL0110 1 10 r Work Conv_Push Plate Down Solenoid Valve OK / NG D-CONV
O_R_WORK1_STOP SL0111 1 11 r Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG D-CONV
O_R_WORK2_STOP SL0112 1 12 r Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG D-CONV
SL0113 1 13 OK / NG D-CONV
SL0114 1 14 Inlet Stopper Up/Dn Solenoide Valve OK / NG Inlet Conv
SN0115 0 15 OK / NG
Notice :
1, I/O => Input = 0
Output = 1
2.D-CONV:Dual Conveyor
3.Port 12:Inlet Conveyor Stopper SOL
E-14 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Mx400_NX12 I/O Check Sheet
Serial NO Date Signee
Description
ANC&DOOR Sensor Part
Examiner
Module No : 02 Address : A Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check Remark
I_F_ANC_UNLOCK SN0200 0 0 f ANC Unlock Sensor OK / NG
I_F_ANC_LOCK SN0201 0 1 f ANC Lock Sensor OK / NG
I_F_NBASE_UP SN0202 0 2 f ANC Up Sensor OK / NG
I_F_NBASE_DN SN0203 0 3 f ANC Dn Sensor OK / NG
I_F_DOOR_LOCK SN0204 0 4 f Door Sensor OK / NG
O_F_DOOR_LOCK 1 5 f Door Locking Signal OK / NG
F_DOOR S/W
Sig
0 6 f Door System Sensor OK / NG
SN0207 0 7 f Floating Sensor OK / NG
I_R_ANC_UNLOCK SN0208 0 8 r ANC Unlock Sensor OK / NG
I_R_ANC_LOCK SN0209 0 9 r ANC Lock Sensor OK / NG
I_R_NBASE_UP SN0210 0 10 r ANC Up Sensor OK / NG
I_R_NBASE_DN SN0211 0 11 r ANC Dn Sensor OK / NG
I_R_DOOR_LOCK SN0212 0 12 r Door Sensor OK / NG
O_R_DOOR_LOCK 1 13 r Door Locking Signal OK / NG
R_DOOR S/W
Sig
0 14 r Door System Sensor OK / NG
SN0215 0 15 r Floating Sensor OK / NG
Notice :
1, I/O => Input = 0
Output = 1
Appendix E-15
Draft
(
)
Check
( )
Approval
(
Mx400_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Lamp&Switch & Key Part
Examiner
Module No : 03 Address : B Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check
비
고
O_BUZZER 1 0 Buzzer OK / NG
O_REDLAMP 1 1 System Fault Lamp (Red) OK / NG
O_GRNLAMP 1 2 System Running Lamp (Green) OK / NG
O_YELLAMP
System Lamp
1 3 System Error Lamp (Yellow) OK / NG
O_R_ANC_UNLOCK SL0304 1 4 r ANC Lock/Unlock Solenoid Valve OK / NG
O_R_NBASE_UP SL0305 1 5 r ANC Up/Dn Solenoid Valve OK / NG P-ANC
I_F_FEEDERKEY 0 6 f Feeder Key Input OK / NG
O_F_FEEDERPKEY 1 7 f Feeder Key LED Output OK / NG
f_FEEDER
KEY
1 8 f Feeder Control Output(To=>SSR1) OK / NG
I_R_FEEDERKEY 0 9 r Feeder Key Input OK / NG
O_R_FEEDERPKEY 1 10 r Feeder Key LED Output OK / NG
r_FEEDER
KEY
1 11 r Feeder Control Output(To=>SSR2) OK / NG
I_STOPKEY 0 12 f/r STOP Key Input OK / NG
O_STOPKEY
STOP KEY
1 13 f/r STOP Key LED Output OK / NG
I_FDOORLOCK,
I_RDOORLOCK
0 14 f/r DOOR Key Input OK / NG
O_FOX_DOOR_LOCK
DOOR KEY
1 15 f/r DOOR Key LED Output OK / NG
Notice:
1, I/O => Input = 0
Output = 1
