Appendix E - 1 7 Draft ( ) Check ( ) Approval ( Mx400_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion R_Conveyor Step Motor Part & SEMEMA Examiner Module No : 11 Address : 9 Rev : 0 Revised date : 2007 / 09/…
E-16 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Mx400_NX12 I/O Check Sheet
Serial NO Date Signee
Description
F_Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 10 Address : 8 Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check Remark
O_CHBEL1STA 1 0 f Work Ent Conv_Belt Start Output OK / NG Inlet Conv
O_CHBEL1LOW 1 1 f Work Ent Conv_Belt Low Speed Output OK / NG Inlet Conv
O_CHBEL1MID 1 2 f Work Ent Conv_Belt Middle Speed Output OK / NG Inlet Conv
O_CHBEL1DIR 1 3 f Work Ent Conv_ Belt Reverse Output OK / NG Inlet Conv
O_CHBEL2STA 1 4 f Work Conv_ Belt Start Output OK / NG
O_CHBEL2LOW 1 5 f Work Conv_ Belt Low Speed Output OK / NG
O_CHBEL2MID 1 6 f Work Conv_ Belt Middle Speed Output OK / NG
O_CHBEL2DIR 1 7 f Work Conv_ Belt Reverse Output OK / NG
O_CHBEL3STA 1 8 f Work Ext Conv_ Belt Start Output OK / NG Outlet onv
O_CHBEL3LOW 1 9 f Work Ext Conv_Belt Low Speed Output OK / NG Outlet onv
O_CHBEL3MID 1 10 f Work Ext Conv_Belt Middle Speed Output OK / NG Outlet onv
O_CHBEL3DIR
TB1 CN1
1 11 f Work Ext Conv_ Belt Reverse Output OK / NG Outlet onv
I_FNEXTIN 0 12 (FRONT CONVEYOR)Next System Input Signal OK / NG
I_FPREVIN 0 13 (FRONT CONVEYOR)Previous System Input Signal OK / NG
O_FNEXTOUT 1 14 (FRONT CONVEYOR)Next System Output Signal OK / NG
O_FPREVOUT
TB1 CN10
1 15
(FRONT CONVEYOR)Previous System Output
Signal
OK / NG
Notice :
1, I/O => Input = 0
Output = 1
2.Ent,Ext Part=>Inlet,Outlet
적용시
공용
Appendix E-17
Draft
(
)
Check
( )
Approval
(
Mx400_NX12 I/O Check Sheet
Serial NO Date Signee
Description
R_Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 11 Address : 9 Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check Remark
O_BELT1STA 1 0 r Work Ent Conv_ Belt Start Output OK / NG
O_BELT1LOW 1 1 r Work Ent Conv_ Belt Low Speed Output OK / NG
O_BELT1MID 1 2 r Work Ent Conv_Belt Middle Speed Output OK / NG
O_BELT1DIR 1 3 r Work Ent Conv_ Belt Reverse Output OK / NG
O_BELT2STA 1 4 r Work Conv_ Belt Start Output OK / NG
O_BELT2LOW 1 5 r Work Conv_ Belt Low Speed Output OK / NG
O_BELT2MID 1 6 r Work Conv_ Belt Middle Speed Output OK / NG
O_BELT2DIR 1 7 r Work Conv_ Belt Reverse Output OK / NG
O_BELT3STA 1 8 r Work Ext Conv_ Belt Start Output OK / NG
O_BELT3LOW 1 9 r Work Ext Conv_ Belt Low Speed Output OK / NG
O_BELT3MID 1 10 r Work Ext r Conv_Belt Middle Speed Output OK / NG
O_BELT3DIR
TB2 CN1
1 11 r Work Ext Conv_ Belt Reverse Output OK / NG
I_RNEXTIN 0 12 (REAR CONVEYOR)Next System Input Signal OK / NG
I_RPREVIN 0 13 (REAR CONVEYOR)Previous System Input Signal OK / NG
O_RNEXTOUT 1 14 (REAR CONVEYOR)Next System Output Signal OK / NG
O_RPREVOUT
TB2 CN10
1 15 (REAR CONVEYOR)Previous System Output Signal OK / NG
Notice :
Dual Conveyor Part
1, I/O => Input = 0
Output = 1
E-18 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Mx400_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Switch&Key Part
Examiner
Module No : 12 Address : A Rev : 0 Revised date : 2007 / 09/ 14
Name Label I/O Port Description Check Remark
I_F_XLMTEMP 0 0 f Linear Motor Temp Signal #01 OK / NG
I_F_Y1LMTEMP 0 1 f Linear Motor Temp Signal #02 OK / NG
I_F_Y2LMTEMP 0 2 f Linear Motor Temp Signal #03 OK / NG
I_R_XLMTEMP 0 3 r Linear Motor Temp Signal #01 OK / NG
I_R_Y1LMTEMP 0 4 r Linear Motor Temp Signal #02 OK / NG
I_R_Y2LMTEMP
C/B CN2
0 5 r Linear Motor Temp Signal #03 OK / NG
SL1206 1 6 OK / NG
SL1207 1 7 OK / NG
SN1208 0 8 OK / NG
SN1209 0 9 OK / NG
OT1210 1 10 f System Runing Lamp OK / NG
OT1211 1 11 r System Runing Lamp OK / NG
O_LAMP OT1212 1 12 Machine LAMP ON/OFF OK / NG
I_AIRLOW SN1213 1 13 Air Pressure Low Sensor OK / NG
O_SVEN P-BOX P1 0 14 SVEN (Servo Voltage Enable) OK / NG
I_EMERGENCY
EMG
/W(N.O)
0 15 Machine Emergency S/W Input OK / NG
Notice
:
1, I/O => Input = 0
Output = 1
