E-20 Mx Series Manual Draft ( ) Check ( ) Approval ( Master-Mx800_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion Left Front Conveyor Sensor & ANC Soleno id Part Examiner Module No : 00 Address : 8 Rev : 3 R…
Appendix E-19
* MODULE DESIGN SHEET LIST for Mx800
MODULE NO. DESCRIPTION
비고
00 Left Front Conveyor Sensor Part & ANC Solenoid Part
01 Left Rear Conveyor Sensor & Solenoid Part
02 Left ANC & DOOR Sensor Part
03 Lamp & Switch & Key Part
10 Left Front Conveyor Step Motor Part & SEMEMA
11 Left Rear Conveyor Step Motor Part & SEMEMA
12 Switch & Key Part
20 Front Trolley(Option)
21 Rear Trolley(Option)
Master VME NXO2V B/D
00 Right Front Conveyor Sensor & ANC Solenoid Part
01 Right Rear Conveyor Sensor & Solenoid Part
02 Right ANC & DOOR Sensor Part
03 Lamp & Switch & Key Part
10 Right Front Conveyor Step Motor Part & SEMEMA
11 Right Rear Conveyor Step Motor Part & SEMEMA
12 Switch & Key Part
20 Front Trolley(Option)
21 Rear Trolley(Option)
Slave VME NXO2V B/D
E-20 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Master-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Left Front
Conveyor Sensor & ANC Solenoid Part
Examiner
Module No : 00 Address : 8 Rev : 3 Revised date : 2007 / 11/ 21
Name Lable I/O Port Description Check
비
고
I_LF_ENTRY_ENT L_SN0000 0 0 Front Conv PCB Entrance Sensor OK / NG
I_LF_ENTRY_WAIT L_SN0001 0 1 L_f Work Conv Entrance Wait Sensor OK / NG
I_LF_WORK1_SET L_SN0002 0 2 L_f Work Conv 1
ST
Set Position Sensor OK / NG
I_LF_WORK1_STOP L_SN0003 0 3 L_f Work Conv 1
ST
Main Stopper Up Sensor OK / NG
I_LF_WORK2_SET L_SN0004 0 4 L_f Work Conv 2
ST
Set Position Sensor OK / NG
PCB(
大
)
I_LF_WORK2_STOP L_SN0005 0 5 L_f Work Conv 2
ST
Main Stopper Up Sensor OK / NG
PCB(
大
)
I_LF_WORK_PHUP L_SN0006 0 6 L_f Work Conv_Push Plate Up Sensor OK / NG
I_LF_WORK_PHDN L_SN0007 0 7 L_f Work Conv_Push Plate Down Sensor OK / NG
L_SP0008 8 Spare
O_LF_WORK_PHUP L_SL0009 1 9 L_f Work Conv_Push Plate Up Solenoid Valve OK / NG
O_LF_WORK_PHDN L_SL0010 1 10 L_f Work Conv_Push Plate Down Solenoid Valve OK / NG
O_LF_WORK1_STOP L_SL0011 1 11 L_f Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG
O_LF_WORK2_STOP L_SL0012 1 12 L_f Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG
L_SP0013 13 Spare
O_LF_ANC_UNLOCK L_SL0014 1 14 L_f ANC Lock/Unlock Solenoid Valve OK / NG
O_LF_NBASE_UP L_SL0015 1 15 L_f ANC Up/Dn Solenoid Valve OK / NG P-ANC
Notice :
1, I/O => Input = 0
Output = 1
2. In case of applying 2.Port 0 Inlet Conveyor, Proceed with Inlet Conv PCB Entrance Sensor
3. In case of applying 3.Port 8 Outlet Conveyor, Proceed with Outlet Conv PCB Exit Sensor
Appendix E-21
Draft
(
)
Check
( )
Approval
(
Master-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Left Rear Conveyor Sensor & Solenoid Part
Examiner
Module No : 01 Address : 9 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
L_SP0100 0 Spare
I_LR_ENTRY_WAIT L_SN0101 0 1 L_r Work Conv Entrance Wait Sensor OK / NG D-CONV
I_LR_WORK1_SET L_SN0102 0 2 L_r Work Conv 1
ST
Set Position Sensor OK / NG D-CONV
I_LR_WORK1_STOP L_SN0103 0 3 L_r Work Conv 1
ST
Main Stopper Up Sensor OK / NG D-CONV
I_LR_WORK2_SET L_SN0104 0 4 L_r Work Conv 2
ST
Set Position Sensor OK / NG D-CONV
I_LR_WORK2_STOP L_SN0105 0 5 L_r Work Conv 2
ST
Main Stopper Up Sensor OK / NG D-CONV
I_LR_WORK_PHUP L_SN0106 0 6 L_r Work Conv_Push Plate Up Sensor OK / NG D-CONV
I_LR_WORK_PHDN L_SN0107 0 7 L_r Work Conv_Push Plate Down Sensor OK / NG D-CONV
L_SP0108 8 Spare
O_LR_WORK_PHUP L_SL0109 1 9 L_r Work Conv_Push Plate Up Solenoid Valve OK / NG D-CONV
O_LR_WORK_PHDN L_SL0110 1 10 L_r Work Conv_Push Plate Down Solenoid Valve OK / NG D-CONV
O_LR_WORK1_STOP L_SL0111 1 11 L_r Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG D-CONV
O_LR_WORK2_STOP L_SL0112 1 12 L_r Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG D-CONV
L_SP0113 13 Spare
L_SL0114 1 14 Inlet Stopper Up/Dn Solenoide Valve OK / NG Inlet Conv
L_SN0115 0 15 INLET STOPPER UP SEN OK / NG Inlet Conv
Notice :
1, I/O => Input = 0
Output = 1
2. D-CONV:Dual Conveyor
3. Port 12:Inlet Conveyor Stopper SOL
