Appendix E-25
Draft
(
)
Check
( )
Approval
(
Master-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Left Rear
Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 11 Address : 9 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
O_ LR_BELT1STA 1 0 L_r Work Ent Conv_ Belt Start Output OK / NG
O_ LR_BELT1LOW 1 1 L_r Work Ent Conv_ Belt Low Speed Output OK / NG
O_ LR_BELT1MID 1 2 L_r Work Ent Conv_Belt Middle Speed Output OK / NG
O_ LR_BELT1DIR 1 3 L_r Work Ent Conv_ Belt Reverse Output OK / NG
O_ LR_BELT2STA 1 4 L_r Work Conv_ Belt Start Output OK / NG
O_ LR_BELT2LOW 1 5 L_r Work Conv_ Belt Low Speed Output OK / NG
O_ LR_BELT2MID 11 6 L_r Work Conv_ Belt Middle Speed Output OK / NG
O_ LR_BELT2DIR 1 7 L_r Work Conv_ Belt Reverse Output OK / NG
O_ LR_BELT3STA 1 8 L_r Work Ext Conv_ Belt Start Output OK / NG
O_ LR_BELT3LOW 1 9 L_r Work Ext Conv_ Belt Low Speed Output OK / NG
O_ LR_BELT3MID 1 10 L_r Work Ext r Conv_Belt Middle Speed Output OK / NG
O_ LR_BELT3DIR
L_TB2 CN1
1 11 L_r Work Ext Conv_ Belt Reverse Output OK / NG
I_ LR_NEXTIN 0 12
(LEFT REAR CONVEYOR)Next System Input
Signal
OK / NG
I_ LR_PREVIN 0 13
(LEFT REAR CONVEYOR)Previous System
Input Signal
OK / NG
O_ LR_NEXTOUT 1 14
(LEFT REAR CONVEYOR)Next System
Output Signal
OK / NG
O_ LR_PREVOUT
L_TB2 CN10
1 15
(LEFT REAR CONVEYOR)Previous System
Output Signal
OK / NG
Notice :
Dual Conveyor Part
1, I/O => Input = 0
Output = 1
E-26 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Master-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Switch & Key Part
Examiner
Module No : 12 Address : A Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check 비 고
I_LF_XLMTEMP 0 0 L_f Linear Motor Temp Signal #01 OK / NG
I_LF_Y1LMTEMP 0 1 L_f Linear Motor Temp Signal #02 OK / NG
I_LF_Y2LMTEMP 0 2 L_f Linear Motor Temp Signal #03 OK / NG
I_LR_XLMTEMP 0 3 L_r Linear Motor Temp Signal #01 OK / NG
I_LR_Y1LMTEMP 0 4 L_r Linear Motor Temp Signal #02 OK / NG
I_LR_Y2LMTEMP
L_C/B CN2
0 5 L_r Linear Motor Temp Signal #03 OK / NG
1 6 M1 Dispenser Air Push signal(Input) OK / NG
1 7
M1 Dispenser Solenoide Valve (Output) –
High(Up), Low(Down)
OK / NG
0 8 M1 Dispenser Up Sensor(Input) OK / NG
0 9 M1 Dispenser Down Sensor(Input) OK / NG
O_LF_RUNLAMP L_OT1210 1 10 L_f System Runing Lamp OK / NG
O_LR_RUNLAMP L_OT1211 1 11 L_r System Runing Lamp OK / NG
O_L_INSIDELAMP L_OT1212 1 12 Left Machine LAMP ON/OFF OK / NG
I_AIRLOW L_SN1213 1 13 Air Pressure Low Sensor OK / NG
O_L_SVEN L_P-BOX P1 0 14 L_SVEN (Servo Voltage Enable) OK / NG
I_EMERGENCY EMG S/W(N.O) 0 15 Machine Emergency S/W Input OK / NG
Notice :
1, I/O => Input = 0
Output = 1
Appendix E-27
Draft
(
)
Check
( )
Approval
(
Master-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Machine State Siganl Part
Examiner
Module No : 13 Address : A Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
0 0 State of M2 Machine (Input) OK / NG
Machine State
1 1 State of M1 Machine (Output) OK / NG
0 2 State of M2 Machine PCB (Input) OK / NG
PCB State
1 3 State of M1 Machine PCB (Output) OK / NG
4
5
6
7
8
9
10
11
12
13
14
15
Notice :
1, I/O => Input = 0
Output = 1
