E-32 Mx Series Manual Draft ( ) Check ( ) Approval ( Slave-Mx800_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion Right ANC & DOOR Sensor Part Examiner Module No : 02 Address : A Rev : 3 Revised date : 2007 /…
Appendix E-31
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Right Rear
Conveyor Sensor & Solenoid Part
Examiner
Module No : 01 Address : 9 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
R_SN0100 0 0 OUTLET STOPPER UP SEN OK / NG Outlet CONV
I_RR_ENTRY_WAIT R_SN0101 0 1 R_r Work Conv Entrance Wait Sensor OK / NG D-CONV
I_RR_WORK1_SET R_SN0102 0 2 R_r Work Conv 1
ST
Set Position Sensor OK / NG D-CONV
I_RR_WORK1_STOP R_SN0103 0 3 R_r Work Conv 1
ST
Main Stopper Up Sensor OK / NG D-CONV
I_RR_WORK2_SET R_SN0104 0 4 R_r Work Conv 2
ST
Set Position Sensor OK / NG D-CONV
I_RR_WORK2_STOP R_SN0105 0 5 R_r Work Conv 2
ST
Main Stopper Up Sensor OK / NG D-CONV
I_RR_WORK_PHUP R_SN0106 0 6 R_r Work Conv_Push Plate Up Sensor OK / NG D-CONV
I_RR_WORK_PHDN R_SN0107 0 7 R_r Work Conv_Push Plate Down Sensor OK / NG D-CONV
R_SP018 8 Spare
O_RR_WORK_PHUP R_SL0109 1 9 R_r Work Conv_Push Plate Up Solenoid Valve OK / NG D-CONV
O_RR_WORK_PHDN R_SL0110 1 10 R_r Work Conv_Push Plate Down Solenoid Valve OK / NG D-CONV
O_RR_WORK1_STOP R_SL0111 1 11 R_r Work Conv 1
ST
Main Stopper Solenoid Valve OK / NG D-CONV
O_RR_WORK2_STOP R_SL0112 1 12 R_r Work Conv 2
ST
Main Stopper Solenoid Valve OK / NG D-CONV
R_SL0113 1 13 OUTLET Stopper Up/Dn Solenoide Valve OK / NG Outlet CONV
R_SP0114 0 Spare
R_SP0115 0 Spare
Notice :
E-32 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Right ANC & DOOR Sensor Part
Examiner
Module No : 02 Address : A Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
I_RF_ANC_UNLOCK R_SN0200 0 0 R_f ANC Unlock Sensor OK / NG
I_RF_ANC_LOCK R_SN0201 0 1 R_f ANC Lock Sensor OK / NG
I_RF_NBASE_UP R_SN0202 0 2 R_f ANC Up Sensor OK / NG
I_RF_NBASE_DN R_SN0203 0 3 R_f ANC Dn Sensor OK / NG
I_RF_DOOR_LOCK R_SN0204 0 4 R_f Door Sensor OK / NG
O_RF_DOOR_LOCK 1 5 R_f Door Locking Signal OK / NG
R_f_DOOR
S/W Sig
0 6 R_f Door System Sensor OK / NG
R_SN0207 0 7 R_f Floating Sensor OK / NG
I_RR_ANC_UNLOCK R_SN0208 0 8 R_r ANC Unlock Sensor OK / NG
I_RR_ANC_LOCK R_SN0209 0 9 R_r ANC Lock Sensor OK / NG
I_RR_NBASE_UP R_SN0210 0 10 R_r ANC Up Sensor OK / NG
I_RR_NBASE_DN R_SN0211 0 11 R_r ANC Dn Sensor OK / NG
I_RR_DOOR_LOCK R_SN0212 0 12 R_r Door Sensor OK / NG
O_RR_DOOR_LOCK 1 13 R_r Door Locking Signal OK / NG
R_r_DOOR
S/W Sig
0 14 R_r Door System Sensor OK / NG
R_SN0215 0 15 R_r Floating Sensor OK / NG
Notice :
Appendix E-33
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Lamp & Switch & Key Part
Examiner
Module No : 03 Address : B Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
O_RR_ANC_UNLOCK R_SL0304 1 4 R_r ANC Lock/Unlock Solenoid Valve OK / NG
O_RR_NBASE_UP R_SL0305 1 5 R_r ANC Up/Dn Solenoid Valve OK / NG P-ANC
I_RF_FEEDERKEY 0 6 R_f Feeder Key Input OK / NG
O_RF_FEEDERPKEY
R_f_FEEDER
KEY
1 7 R_f Feeder Key LED Output OK / NG
O_RF_FEED_CONROL R_OT0308 1 8 R_f Feeder Control Output(To=>SSR1) OK / NG
I_RR_FEEDERKEY 0 9 R_r Feeder Key Input OK / NG
O_RR_FEEDERPKEY
R_r_FEEDER
KEY
1 10 R_r Feeder Key LED Output OK / NG
O_RR_FEED_CONROL R_OT0311 1 11 R_r Feeder Control Output(To=>SSR2) OK / NG
I_R_STOPKEY 0 12 Right(f/r) STOP Key Input OK / NG
O_R_STOPKEY
R_STOP KEY
1 13 Right(f/r) STOP Key LED Output OK / NG
I_R_FDOORLOCK,
I_R_RDOORLOCK
0 14 Right(f/r) DOOR Key Input OK / NG
O_R_FOX_DOOR_LOCK
R_DOOR KEY
1 15 Right(f/r) DOOR Key LED Output OK / NG
Notice :
