Appendix E - 3 5 Draft ( ) Check ( ) Approval ( Slave-Mx800_NX12 I/O Check Sheet Serial NO Date Signee Desc ript ion Right Rear Conveyor Step Motor Part & SEMEMA Examiner Module No : 11 Address : 9 Rev : 3 Revised da…
E-34 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Right Front
Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 10 Address : 8 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
O_RF_CHBEL1STA 1 0 R_f Work Ent Conv_Belt Start Output OK / NG
O_ RF_CHBEL1LOW 1 1 R_f Work Ent Conv_Belt Low Speed Output OK / NG
O_ RF_CHBEL1MID 1 2 R_f Work Ent Conv_Belt Middle Speed Output OK / NG
O_ RF_CHBEL1DIR 1 3 R_f Work Ent Conv_ Belt Reverse Output OK / NG
O_ RF_CHBEL2STA 1 4 R_f Work Conv_ Belt Start Output OK / NG
O_ RF_CHBEL2LOW 1 5 R_f Work Conv_ Belt Low Speed Output OK / NG
O_ RF_CHBEL2MID 1 6 R_f Work Conv_ Belt Middle Speed Output OK / NG
O_ RF_CHBEL2DIR 1 7 R_f Work Conv_ Belt Reverse Output OK / NG
O_ RF_CHBEL3STA 1 8 R_f Work Ext Conv_ Belt Start Output OK / NG Outlet Conv
O_ RF_CHBEL3LOW 1 9 R_f Work Ext Conv_Belt Low Speed Output OK / NG Outlet Conv
O_ RF_CHBEL3MID 1 10 R_f Work Ext Conv_Belt Middle Speed Output OK / NG Outlet Conv
O_ RF_CHBEL3DIR
R_TB1 CN1
1 11 R_f Work Ext Conv_ Belt Reverse Output OK / NG Outlet Conv
I_ RF_NEXTIN 0 12
(RIGHT FRONT CONVEYOR) Next System
Input Signal
OK / NG
I_ RF_PREVIN 0 13
(RIGHT FRONT CONVEYOR) Previous
System Input Signal
OK / NG
O_ RF_NEXTOUT 1 14
(RIGHT FRONT CONVEYOR) Next System
Output Signal
OK / NG
O_ RF_PREVOUT
R_TB1 CN10
1 15
(RIGHT FRONT CONVEYOR) Previous
System Output Signal
OK / NG
Notice :
1,
Appendix E-35
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Right Rear
Conveyor Step Motor Part & SEMEMA
Examiner
Module No : 11 Address : 9 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
O_RR_BELT1STA 1 0 R_r Work Ent Conv_ Belt Start Output OK / NG
O_ RR_BELT1LOW 1 1 R_r Work Ent Conv_ Belt Low Speed Output OK / NG
O_ RR_BELT1MID 1 2 R_r Work Ent Conv_Belt Middle Speed Output OK / NG
O_ RR_BELT1DIR 1 3 R_r Work Ent Conv_ Belt Reverse Output OK / NG
O_ RR_BELT2STA 1 4 R_r Work Conv_ Belt Start Output OK / NG
O_ RR_BELT2LOW 1 5 R_r Work Conv_ Belt Low Speed Output OK / NG
O_ RR_BELT2MID 1 6 R_r Work Conv_ Belt Middle Speed Output OK / NG
O_ RR_BELT2DIR 1 7 R_r Work Conv_ Belt Reverse Output OK / NG
O_ RR_BELT3STA 1 8 R_r Work Ext Conv_ Belt Start Output OK / NG
O_ RR_BELT3LOW 1 9 R_r Work Ext Conv_ Belt Low Speed Output OK / NG
O_ RR_BELT3MID 1 10 R_r Work Ext r Conv_Belt Middle Speed Output OK / NG
O_ RR_BELT3DIR
R_TB2 CN1
1 11 R_r Work Ext Conv_ Belt Reverse Output OK / NG
I_ RR_NEXTIN 0 12
(RIGHT REAR CONVEYOR) Next System
Input Signal
OK / NG
I_ RR_PREVIN 0 13
(RIGHT REAR CONVEYOR) Previous System
Input Signal
OK / NG
O_ RR_NEXTOUT 1 14
(RIGHT REAR CONVEYOR) Next System
Output Signal
OK / NG
O_ RR_PREVOUT
R_TB2 CN10
1 15
(RIGHT REAR CONVEYOR) Previous System
Output Signal
OK / NG
Notice :
1,
E-36 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Switch & Key Part
Examiner
Module No : 12 Address : A Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
I_RF_XLMTEMP 0 0 R_f Linear Motor Temp Signal #01 OK / NG
I_RF_Y1LMTEMP 0 1 R_f Linear Motor Temp Signal #02 OK / NG
I_RF_Y2LMTEMP 0 2 R_f Linear Motor Temp Signal #03 OK / NG
I_RR_XLMTEMP 0 3 R_r Linear Motor Temp Signal #01 OK / NG
I_RR_Y1LMTEMP 0 4 R_r Linear Motor Temp Signal #02 OK / NG
I_RR_Y2LMTEMP
R_C/B CN2
0 5 R_r Linear Motor Temp Signal #03 OK / NG
1 6 M2 Dispenser Air Push signal(Input) OK / NG
1 7
M2 Dispenser Solenoide Valve (Output) –
High(Up), Low(Down)
OK / NG
0 8 M2 Dispenser Up Sensor(Input) OK / NG
0 9 M2 Dispenser Down Sensor(Output) OK / NG
O_RF_RUNLAMP R_OT1210 1 10 R_f System Runing Lamp OK / NG
O_RR_RUNLAMP R_OT1211 1 11 R_r System Runing Lamp OK / NG
O_R_LAMP R_OT1212 1 12 RIGHT Machine LAMP ON/OFF OK / NG
O_R_SVEN R_P-BOX P1 0 14 R_SVEN (Servo Voltage Enable) OK / NG
Notice :
1,
