E-38 Mx Series Manual
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Right Front Trolley Part
Examiner
Module No : 20 Address : 8 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
0 0 R_f Trolley Feeder Base Down Sensor OK / NG
1 1 OK / NG
0 2 R_f Trolley Feeder Base Set Position S/W(Left) OK / NG
0 3 R_f Trolley Feeder Base Set Position S/W(Right) OK / NG
1 4 R_f Trolley Connector Block Up Sensor OK / NG
0 5 OK / NG
0 6 R_f Trolley Feeder Base In Position Sensor(Left) OK / NG
1 7 R_f Trolley Feeder Base In Position Sensor(Right) OK / NG
1 8 R_f Trolley Feeder Base UP Sol Valve OK / NG
0 9 R_f Trolley Connector Block UP Sol Valve OK / NG
1 10 R-f Trolley Feeder Lock S/W OK / NG
1 11 R-f Trolley Feeder Unlock S/W OK / NG
0 12 R-f Trolley Feeder Lock S/W LED(GRN) OK / NG
1 13 R-f Trolley Feeder Unlock S/W LED(WHI) OK / NG
0 14 R-f Trolley Feeder Base DN Sol Valve OK / NG
1 15 R-f Trolley Connector Block DN Sol Valve OK / NG
Notice :
1,
Appendix E-39
Draft
(
)
Check
( )
Approval
(
Slave-Mx800_NX12 I/O Check Sheet
Serial NO Date Signee
Description
Right Rear Trolley Part
Examiner
Module No : 21 Address : 9 Rev : 3 Revised date : 2007 / 11/ 21
Name Label I/O Port Description Check
비
고
0 0 R-r Trolley Feeder Base Down Sensor OK / NG
1 1 OK / NG
0 2 R_r Trolley Feeder Base Set Position S/W(Left) OK / NG
0 3 R-r Trolley Feeder Base Set Position S/W(Right) OK / NG
1 4 R-r Trolley Connector Block Up Sensor OK / NG
0 5 OK / NG
0 6 R_r Trolley Feeder Base In Position Sensor(Left) OK / NG
1 7 R-r Trolley Feeder Base In Position Sensor(Right) OK / NG
1 8 R-r Trolley Feeder Base UP Sol Valve OK / NG
0 9 R-r Trolley Connector Block UP Sol Valve OK / NG
1 10 R-r Trolley Feeder Lock S/W OK / NG
1 11 R-r Trolley Feeder Unlock S/W OK / NG
0 12 R-r Trolley Feeder Lock S/W LED(GRN) OK / NG
1 13 R-r Trolley Feeder Unlock S/W LED(WHI) OK / NG
0 14 R-r Trolley Feeder Base DN Sol Valve OK / NG
1 15 R_r Trolley Connector Block DN Sol Valve OK / NG
Notice :
1,
Appendix F-1
F. BOM Tree
Mx100 Total Assy BOM
(MODULE) (SUB1) (SUB2)
826630-000001 26631-00000-000
Mx100 Main Frame Assy
26632-00000-000
XY-Gantry Assy
26633-00000-000 26633-10000-000
Head Total Assy 4M Head Assy
26634-00000-000 25504-11000-100
Vision Assy FOV07 1H CAMERA 2
26634-20000-000
FOV24 2H ST CAMERA
26536-00000-000
Conveyor Assy
26117-10000-000B
M-ANC ASSY
26008-20000-100
C-Feeder Base Assy
26639-00000-000
Cover Assy
