SPECIFICATIONS
Item
Specifications
M/MU
Min.: 50
×
50 , Max.: 330
×
250 , Thickness: 0.5 to 4.0
Print-board dimensions
(mm)
L
Min.: 50
×
50 , Max.: 330
×
250 , Thickness: 0.5 to 4.0
Mask frame (mm)
736
×
736, 650
×
550, 600
×
550
Squeegee shape
High-speed-print squeegee (Standard), High-speed-print metal squeegee, Advanced
squeegee, Metal squeegee, Flat squeegee, Square squeegee, Sword squeegee,
Cartridge head (Option)
Squeegee length (mm)
M/MU: 350 L: 530
Squeegee speed (mm/
s
)
5 to 400
Squeegee pressure
(
N
/mm)
High-speed-print squeegee (In the case of 350 mm long): 5
×
10
-2
to 100
×
10
-2
(Recommended printing pressure: 10
×
10
-2
to 15
×
10
-2
In case of 10
×
10
-2
or less,
printing may not be stable.)
Squeegee operation
Selectable between single squeegee and double squeegee
Board positioning
reference
Center (For the end face, squeegee parallel adjustment is required.
Please consult us.)
Board fixing method
Mechanically-clamping method (Standard), Board vacuum method (Option)
Mask-frame alignment
correction value
X and Y direction:
±
5 mm Rotating direction:
±
1.2
°
Clearance (mm)
−
0.5 to
+
3
Back-of-mask cleaning
function
Dry process or wet process (Selectable, Combinable)
Mask-cleaning tact time
Standard 26
s
(Varies depending on board size or cleaning speed.)
[Dry process 1 cycle ]
Mask-cleaning-paper
dimensions
1.5 type (Internal diameter 38 mm) Paper tube Length 18 m Width M/MU: 350 mm,
L: 530 mm
Board vacuuming
equipment
SP80V: Blower, Vacuum pump (Standard),
SP60P: Blower (Standard), Vacuum pump (Option)
Inspection function
(SP80V only)
Inspection targets: area, position, bridge Number of inspection points: 30,000
(Standard)
M/MU
W: 1760 (Conveyor end face), D: 1650, H: 1430, 2000 (Including PATLITE)
Outside dimension (mm)
L
W: 1940 (Conveyor end face), D: 1910, H: 1430, 2000 (Including PATLITE)
Mass (
kg
)
M: 1450 , MU: 1550 , L: 1730 (Not including the blower)
Normal
voltage
M: Three-phase 200
±
10 VAC
MU/L: Three-phase 200
±
10 VAC or Three-phase 400
±
10 VAC
Frequency
50/60 Hz
±
5%
Rated capacity
SP80V: 3.6 kVA , SP60P: 3.1 kVA (Vacuum pump included: 3.6 kVA)
Power source
Input voltage
M: 200/220 VAC (M does not support the combination of 220 VAC and 50 Hz.)
MU/L: 380/400/420/480/200/220 VAC
Supply air pressure
0.49 MPa to 0.78 MPa Supply 30 L/min
Environmental condition
Temperature: 10
°
C to 35
°
C
Humidity: 25% to 60% (No condensation)
Transportation and
storage condition
Temperature:
−
20
°
C to 60
°
C
Humidity: 75% (No condensation)
Altitude
Less than 1000 m above sea level
Noise
< 74 dB (A)
LED class Class 1
∗
The options support the changes of the board flow direction and the reference position.
