3-5 3 スプライシングカセット (GAK-0804/PS) 2/3 Splicing Cassette (GAK-0804/PS) 2/3 9 3 5 6 2 1 7 8 22 24 26 25 28 27 19 20 21 19 20 21 23 17 16 11 15 18 14 12 10 13 4

100%1 / 164
3-4
3
スプライシングカセット(GAK-0804/PS) 1/3
Splicing Cassette (GAK-0804/PS) 1/3
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
3-5
3
スプライシングカセット(GAK-0804/PS) 2/3
Splicing Cassette (GAK-0804/PS) 2/3
9
3
5
6
2
1
7
8
22
24
26
25
28
27
19
20
21
19
20
21
23
17
16
11
15
18
14
12
10
13
4
3-6
3
スプライシングカセット(GAK-0804/PS) 2/3
Splicing Cassette (GAK-0804/PS) 2/3
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 4-708-510-01
ﾛ
-
ﾗ
ROLLER
1
2 4-708-509-01
ﾛ
-
ﾗ
ﾋﾟﾝ
ROLLER PIN
1
3 X-4700-015-2
ｶﾊﾞ
-
ﾋﾟﾝ
ASSY
COVER PIN ASSY
1
4 7-682-249-02
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
1
+K3*10
5 7-682-247-02
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
1
+K3*6
6 X-4700-016-2
ﾃ
-
ﾌﾟ
ｵｻｴ
ASSY
TAPE RETAINER ASSY
1
7 7-624-000-05
E
ｶﾞﾀ
ﾄﾒﾜ
(3)
E-RING(3)
1
FOR AXIS
8 4-702-714-01
ﾃ
-
ﾌﾟ
ｵｻｴ
ﾈｼﾞﾘｺｲﾙ
ﾊﾞﾈ
TAPE RETAINER SPRING TENSION
1
9 X-4700-024-3
ﾒｲﾝ
ｼﾔ
-
ｼ
ASSY
MAIN CHASSIS ASSY
1
8mm Paper
10 4-706-624-11
ｸﾗﾝﾌﾟ
ﾚﾊﾞ
-
ｷﾔﾂﾌﾟ
CLAMP LEVER CAP
1
11 X-4700-102-1
ｸﾗﾝﾌﾟ
ﾚﾊﾞ
-
ｶﾞｲﾄﾞ
ASSY
CLAMP LEVER GUIDE ASSY
1
12 4-702-739-01
U
ﾅﾂﾄ
U NUT
1
M5
13 7-688-000-04
ﾜﾂｼﾔ
WASHER
1
5
14 7-681-000-12
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
2
+K4*8
15 4-702-718-01
ｸﾗﾝﾌﾟ
ｱﾂｼﾕｸ
ﾊﾞﾈ
CLAMP COMPRESSION SPRING
1
16 4-702-755-01
ｸﾗﾝﾌﾟ
ﾌﾞﾛﾂｸ
CLAMP BLOCK
1
17 7-626-314-01
ｽﾌﾟﾘﾝｸﾞ
ﾋﾟﾝ
SPRING PIN
1
2*5
18 4-702-698-03
ｸﾗﾝﾌﾟ
ﾋﾟﾝ
CLAMP PIN
1
19 7-684-000-02
ﾛﾂｶｸ
ﾅﾂﾄ
HEX NUT
2
M4, TYPE2
20 7-688-000-12
ｽﾌﾟﾘﾝｸﾞ
ﾜﾂｼﾔ
SPRING WASHER
2
SW4, TYPE2
21 7-688-000-03
ﾜﾂｼﾔ
WASHER
2
W4
22 4-702-691-02
ｲﾁｷﾞﾒ
ﾋﾟﾝ
POSITIONING PIN
1
23 4-702-729-01
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
2
+K4*5
24 4-702-692-02
ｲﾁｷﾞﾒ
ﾍﾝｼﾝ
ﾋﾟﾝ
POSITIONING ECCENTRIC PIN
1
25 2-593-664-01
ﾊﾞﾈ
ｶｹ
ﾌﾟﾚ
-
ﾄ
SPRING HOOK PLATE
1
26 2-593-803-02
ﾃ
-
ﾌﾟ
ｵｻｴ
ﾋﾂﾊﾟﾘ
ﾊﾞﾈ
TAPE RETAINER TENSION SPRING
1
