5-1 1 5 スプライシングカセット (GAK-1204/ES) 3/3 Splicing Cassette (GAK-1204/ES) 3/3 ｲﾗｽﾄ番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 27 4-706-629-02 ｶｾﾂﾄ ｼ - ﾙ CASSETTE SEAL 1 28 7-682-247…

100%1 / 164
5-10
5
スプライシングカセット(GAK-1204/ES) 3/3
Splicing Cassette (GAK-1204/ES) 3/3
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 X-2108-621-1
ﾏｷﾄﾘ
ﾚﾊﾞ
-(3)ASSY
TAKE-UP LEVER (3) ASSY
1
2 2-669-917-01
ﾛ
-
ﾗ
ﾚﾊﾞ
-
ROLLER LEVER
1
3 2-669-891-01
ﾍﾞｱﾘﾝｸﾞ
ｼﾔﾌﾄ
(12mm)
BEARING SHAFT (12mm)
1
4 2-669-910-01
ﾃ
-
ﾌﾟ
ｵｻｴ
ﾛ
-
ﾗ（
12mm)
TAPE RETAINER ROLLER (12mm)
1
5 3-701-447-11
10
ﾎﾟﾘ
ﾜﾂｼﾔ
WASHER
2
W10
6 7-682-248-02
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
1
+K 3*8
7 X-4700-022-1
ﾎｲ
-
ﾙ
ASSY
WHEEL ASSY
1
8 X-4700-021-1
ﾌｲ
-
ﾄﾞ
ﾚﾊﾞ
- ASSY
FEED LEVER ASSY
1
9 X-4700-051-4
ﾃ
-
ﾌﾟ
ｶﾊﾞ
- ASSY
TAPE COVER ASSY
1
10 3-701-443-11
5
ﾌｱｲ
ﾎﾟﾘ
ﾜﾂｼﾔ
WASHER
1
W5
11 3-701-446-01
8
ﾎﾟﾘ
ﾜﾂｼﾔ
WASHER
2
W8
12 4-702-694-02
ｲﾁｷﾞﾒ
ﾚﾊﾞ
-
ｼﾔﾌﾄ
POSITIONING LEVER SHAFT
1
13 4-702-709-03
ｲﾀ
ﾊﾞﾈ
PLATE SPRING
1
14 4-702-721-03
ﾘﾝｸ
ﾋﾟﾝ
LINK PIN
1
15 4-702-723-01
ﾊﾞﾈ
ｶｹ
ﾈｼﾞ
SPRING HOOK SCREW
1
16 4-702-731-01
ﾊﾞﾈ
ｵｻｴｲﾀ
SPRING RETAINER PLATE
1
17 4-702-734-02
ﾊﾞﾈ
ｶｹ
ﾈｼﾞ
SPRING HOOK SCREW
1
18 4-702-736-01
ﾃ
-
ﾌﾟ
ｵｻｴ
ﾛﾂｸ
ﾚﾊﾞ
-
TAPE RETAINER LOCK LEVER
1
19 4-702-744-02
ｲﾁｷﾞﾒ
ﾚﾊﾞ
-
POSITIONING LEVER
1
20 4-702-763-01
ﾋﾂﾊﾟﾘ
ﾊﾞﾈ
TENSION SPRING
1
21 4-702-849-03
ﾌｲ
-
ﾄﾞ
ﾚﾊﾞ
-
ﾋﾂﾊﾟﾘ
ﾊﾞﾈ
FEED LEVER TENSION SPRING
1
22 4-702-854-02
ｶﾊﾞ
-
ｼﾔﾌﾄ
COVER SHAFT
1
23 4-702-861-01
ｲﾁｷﾞﾒ
ﾚﾊﾞ
-
ｱﾂｼﾕｸ
ﾊﾞﾈ
POSITIONING LEVER COMPRESSION SPRING
1
24 4-702-862-02
ﾏｷﾄﾘ
ﾚﾊﾞ
-
ﾋﾂﾊﾟﾘ
ﾊﾞﾈ
TAKE-UP LEVER TENSION SPRING
1
25 4-702-864-02
ﾒｲﾝ
ｼﾔﾌﾄ
MAIN SHAFT
1
26 4-702-865-05
ﾌｲ
-
ﾄﾞ
ｵｸﾘ
ｲﾁｷﾞﾒ
ﾋﾟﾝ
FEED POSITIONING PIN
1
5-11
5
スプライシングカセット(GAK-1204/ES) 3/3
Splicing Cassette (GAK-1204/ES) 3/3
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
27 4-706-629-02
ｶｾﾂﾄ
ｼ
-
ﾙ
CASSETTE SEAL
1
28 7-682-247-02
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
2
+K 3*6
29 7-684-000-01
ﾛﾂｶｸ
ﾅﾂﾄ
M3, TYPE2
HEX NUT M3, TYPE2
2
30 7-684-000-02
ﾛﾂｶｸ
ﾅﾂﾄ
M4, TYPE2
HEX NUT M4, TYPE2
1
31 7-684-000-08
ﾛﾂｶｸ
ﾅﾂﾄ
M3, TYPE3
HEX NUT M3, TYPE3
1
32 7-688-000-11
ｽﾌﾟﾘﾝｸﾞ
ﾜﾂｼﾔ
3, TYPE2
SPRING WASHER 3, TYPE2
4
SW3, TYPE2
33 7-688-000-12
ｽﾌﾟﾘﾝｸﾞ
ﾜﾂｼﾔ
4, TYPE2
SPRING WASHER 4, TYPE2
1
SW4, TYPE2
34 7-681-000-12
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ｻﾗ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
4
+K 4*8
35 7-681-000-44
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ﾅﾍﾞ
ｺﾈｼﾞ
(+CROSS)
FLAT HEAD SCREW
1
+P 3*5
36 2-669-911-02
ｶﾞｲﾄﾞ
ﾛ
-
ﾗ
(1)(12mm)
GUIDE ROLLER (1)(12mm)
1
37 2-669-872-01
ﾛ
-
ﾗ
ｼﾔﾌﾄ
(1)(12mm)
ROLLER SHAFT (1)(12mm)
1
38 2-669-899-02
ｵｻｴ
ﾈｼﾞﾘ
ｺｲﾙ
ﾊﾞﾈ
RETAINER SPRING TENSION
1
39 7-624-000-05
E
ｶﾞﾀ
ﾄﾒﾜ
3 (
ｼﾞｸﾖｳ
)
E-RING 3 (FOR AXIS)
1
