45-B 補給/NG排出部:X10 Supply/NG ex haust Section:X10 パーツレイアウト Kit No. キット 品番 Kit Name キット名称 MTKA012196AA セクションNo. PARTS LAYOUT Section No. - - O183 ( KMTKA012196AA-05-2 )
Ref
No.
Remarks R
1
Q'ty
45-A
補給/NG排出部:X10
Supply/NG exhaust Section:X10
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA012196AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
GUIDE
4
1 MTPS000735AD
BLOCK
2
2 KXFB015CA00
BRACKET
1
3 MTPB011012AE
BRACKET
1
4 MTPB011010AC
BRACKET
1
5 MTPB011017AD
BRACKET
1
6 MTPB011008AC
BRACKET
1
7 MTPB011003AC
BRACKET
3
8 N210004500AA
BRACKET
2
9 KXFB00JJA01
PLATE
1
10 MTPB011108AD
LEVER
1
11 MTPB012118AB
COVER
1
12 MTPB014182AA
BRACKET
2
13 MTPB014183AB
BRACKET
1
14 MTPB014476AC
BRACKET
1
15 MTPB014477AD
STOPPER-PLATE
1
16 MTPB014732AA
BRACKET
1
17 MTPB014733AB
NUT-PLATE
1
18 KXFB03UPA00
BRACKET
1
19 MTKP005672AC
BRACKET
1
20 MTKP007751AB
MAGNET
2
21 N980C1613 C-161-3
SCREW
2
22 N510018203AA
Cross recessed Countersunk head machine screw M6X16-4.8 A2J (Trivalen
PRECISION-LEVEL
2
23 KXF0DXU6A00 100WATER LEVEL
SCREW
4
24 N510018241AA
Cross recessed Truss head machine screw M3X18-4.8 A2J (Trivalent)
SPACER
2
25 N510021002AA CF-310E
SWITCH
1
26 N510037850AA
S
D4NH-1BBC
BOLT
2
27 N510001582AA SRBS-M4X30
JOINT
1
28 KXF06F4AA00 53015030-WM
SPACER
12
29 N510038529AA CF-308ZE
JOINT
2
30 N510066711AA KQ2S04-M5A
BOLT
2
31 MTNK003371AA CQ-M3X35L
SPACER
1
32 N510020914AA ASF-615E
CABLE-SUPPORT
11
33 N510048517AA FT4
SWITCH
1
34 MTKP009652AA D2VW-01L2A-3MS
CYLINDER
1
35 MTKP008365AA
PLATE
1
36 MTPB018508AA
NUT-PLATE
1
37 MTPB018960AA
NUT-PLATE
1
38 MTPB019107AA
STOPPER
1
39 MTPB018893AA
STOPPER
2
40 MTPB019852AA
BOLT
1
41 N510067811AA
Ultra Low Head Cap Screw M5X10-8.8 A2J(Trivalent)
SPACER
1
42 MTNK004121AA CF-503ZE
SPACER
2
43 N510021006AA CF-407E
BOLT
2
44 N510017628AA
Hexagon socket Flat head bolt M4X8-10.9 A2J (Trivalent)
O182
--
( KMTKA012196AA-05-1 )
45-B
補給/NG排出部:X10
Supply/NG exhaust Section:X10
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
MTKA012196AA
セクションNo.
PARTS LAYOUT
Section No.
--
O183
( KMTKA012196AA-05-2 )
Ref
No.
Remarks R
1
Q'ty
45-B
補給/NG排出部:X10
Supply/NG exhaust Section:X10
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA012196AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COLLAR
4
1 KXFB014DA00
SHAFT
2
2 MTPA015828AC
COLLAR
2
3 MTPA015962AC
COLLAR
2
4 KXFB015BA00
LEVER
4
5 MTPA015829AD
STOPPER
4
6 KXFB014RA00
BRACKET
1
7 MTPB009520AD
BRACKET
2
8 MTPB011029AA
BRACKET
2
9 MTPB011030AA
BRACKET
2
10 MTPB014824AA
BRACKET
1
11 MTPB014083AB
SPRING
4
12 KXF0DWZ8A00 6657
BEARING
8
13 MTNB000925AA F-604ZZ1/1K
SPACER
4
14 N510019915AA CB-406E
SPACER
2
15 N510017099AA CB-415E
NUT
4
16 N510017865AA
Hexagon nut Type-3 Best class M5-6H-4T A2J (Trivalent)
BOLT
2
17 N510017360AA
Hexagon socket head cap screw M4X25-10.9 A2J (Trivalent) Full thread
SPACER
2
18 N510030564AA CB-409E
SLIT
1
19 N510014389AA E39-S65C
SENSOR
1
20 MTKP007850AB E3Z-T61 2M
CYLINDER
1
21 MTKP008366AB
CYLINDER
1
22 MTKP008367AB
SPACER
4
23 N510017096AA CB-404E
SLIT
1
24 MTNS000728AA E39-S65B
O184
--
( KMTKA012196AA-05-2 )
