8-D X軸:NPM-WX X-Ax is:NPM-W X パーツレイアウト Kit No. キット 品番 Kit Name キット名称 MTKA009640AA セクションNo. PARTS LAYOUT Section No. - - S35 ( KMTKA009640AA-11-4 )
Ref
No.
Remarks R
1
Q'ty
8-C
X軸:NPM-WX
X-Axis:NPM-WX
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA009640AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
X-PLATE
1
1 MTKP005431AB
PLATE
1
2 MTKP004563AA
BRACKET
1
3 MTKP004562AA
STOPPER
4
4 N210109236AB
WASHER
4
5 MTPA019265AA
PLATE
1
6 MTPB005911AC
COVER
1
7 N210198601AC
FAN
1
8 MTND000069AA
S
109P0424N7D04
PIN
4
9 N510020608AA MMS5-15
PIN
2
10 N510040341AA MMSTH5-15
SPACER
4
11 N510044825AA 3382330-40075
BOLT
4
12 N510067770AA Low Head Cap Screw M3X20-8.8 A2J(Trivalent)
BOLT
2
13 MTNK000533AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent) (MEC process:
PIN
4
14 N510020589AA MMS3-8
BOLT
1
15 N510028457AA SRBS-M3X16
SPACER
1
16 N510062418AA CL-311E
SCREW
2
17 N510018434AA
Hexagon socket set screw Flat point M4X4-45H A2J (Trivalent)
SPACER
4
18 N510029514AA ASF-409E
S34
--
( KMTKA009640AA-11-3 )
8-D
X軸:NPM-WX
X-Axis:NPM-WX
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
MTKA009640AA
セクションNo.
PARTS LAYOUT
Section No.
--
S35
( KMTKA009640AA-11-4 )
Ref
No.
Remarks R
1
Q'ty
8-D
X軸:NPM-WX
X-Axis:NPM-WX
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA009640AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BLOCK
2
1 MTKP011203AA
SPACER
2
2 MTKP011204AA
BRACKET
1
3 MTPB002990AB
BRACKET
1
4 MTPB008447AE
BRACKET
1
5 MTPB001093AA
BRACKET
1
6 MTPB008446AE
COVER
1
7 MTPB008654AB
COVER
1
8 MTPB008653AC
COUPLER
1
9 MTNP000908AA MA-MS-SCL4-06X08-A
SPACER
4
10 N510065911AA CL-515E
GREASE-NIPPLE
4
11 N560AMT6-130 A-MT6X1-Type(M6X1)
JOINT
4
12 N510066524AA KQ2H04-M5A
SPACER
2
13 N510036999AA ASF-2605E
SPACER
1
14 N510019918AA CF-406E
SPACER
2
15 MTNK001428AA CL-402.5E
SPACER
4
16 MTNK000653AA CL-404E
SPACER
4
17 N510019892AA ASF-412E
SPACER
2
18 N510062648AA CL-303E
BOLT
4
19 N510017520AA
Hexagon socket button head screw M4X16-10.9 A2J (Trivalent)
SCREW
6
20 N510018278AA
Cross recessed Truss head machine screw M4X5-4.8 A2S (Trivalent)
BOLT
11
21 N510017533AA
SSS 003 Hexagon socket button head screw M4X5-10.9 A2J (Trivalent)
BOLT
1
22 N510017536AA
SSS 003 Hexagon socket button head screw M4X8-10.9 A2J (Trivalent)
CABLE-SUPPORT
1
23 N510041957AA TM2S8-M
S36
--
( KMTKA009640AA-11-4 )
