Page SAMSUNG TECHWIN 1 17 SM411 V is io n B oa rd In ter fa ce CN5 CN2 CN1 CN3 J1 CN4 J2 J3 J4 J5 J6 CH1 CH2 DSUB-15PIN DSUB-15PIN DSUB-15PIN DSUB-44PIN FCI 9PIN FCI 9PIN DSUB-15PIN DSUB-15PIN +12V/12G,+HD/-HD,+VD/-VD(CH…
Page
SAMSUNG TECHWIN
116
SM411
Step Motor Interface (Conveyor Belt)
NO. PART NO. PART NAME Q'TY TYPE REMARK
1
J90831126A BW12,BS12 DRV COMMAND CABLE ASSY SM33-VM017
2
J90831127A BW34,BS34 DRV COMMAND CABLE ASSY SM33-VM018
4
J90831277A BS1-1 MOTOR EXT CABLE ASSY SM33-CS028-1
3
J90831278A BS1-2 MOTOR EXT CABLE ASSY SM33-CS028-2
5
J90831279A BW1-1 MOTOR EXT CABLE ASSY SM33-CS028-3
6
J90831280A BW1-2 MOTOR EXT CABLE ASSY SM33-CS028-4
7
J90831281A BW2-1 MOTOR EXT CABLE ASSY SM33-CS028-5
8
J90831282A BW2-2 MOTOR EXT CABLE ASSY SM33-CS028-6
9
J90831283A BS2-1 MOTOR EXT CABLE ASSY SM33-CS028-7
10
J90831284A BS2-2 MOTOR EXT CABLE ASSY SM33-CS028-8
11
J90831090A SHUTTLE,CONV BELT STEP POWER CABLE ASSY SM33-PW028
12
J90831207A BELT MOTOR(BS1-1) CABLE ASSY SM33-CS020
13
J90831208A BELT MOTOR(BS1-2) CABLE ASSY SM33-CS021
14
J90831209A BELT MOTOR(BW1-1) CABLE ASSY SM33-CS022
15
J90831210A BELT MOTOR(BW1-2) CABLE ASSY SM33-CS023
16
J90831211A BELT MOTOR(BW2-1) CABLE ASSY SM33-CS024
17
J90831212A BELT MOTOR(BW2-2) CABLE ASSY SM33-CS025
18
J90831213A BELT MOTOR(BS2-1) CABLE ASSY SM33-CS026
19
J90831214A BELT MOTOR(BS2-2) CABLE ASSY SM33-CS027
20
21
22
23
24
25
26
27
P art L is t
Page
SAMSUNG TECHWIN
117
SM411
Vision Board Interface
CN5
CN2
CN1
CN3
J1
CN4
J2
J3
J4
J5
J6
CH1
CH2
DSUB-15PIN
DSUB-15PIN
DSUB-15PIN
DSUB-44PIN
FCI 9PINFCI 9PIN
DSUB-15PIN DSUB-15PIN
+12V/12G,+HD/-HD,+VD/-VD(CH1,CH2)
S M33_VIS 013
S M33_VIS 001(S M33_V IS 003)
DSUB-9PIN
FID_CAMFID_CAM
S M33_VIS 005(S M33_V IS 007)
S M33_VIS 002
S M33_VIS 008(S M33_V IS 010)
S M33_VIS 009
S M33_VIS 006
S M33_VIS 004
S M33_VIS 011
NEXTEYE B/D
ME G A : S M33_V IS 012
VISION MUX B/D
TO VME
FIX CAM. #1
FIDUCIAL CAM.
INDUSTIAL PC
FLAT CABLE
CAMERA IO B/D
FLY CAM.1
FLY CAM.2
FLY CAM.3
FLY CAM.4
FLY CAM.5
FLY CAM.6
FIX CAM. #2
Page
SAMSUNG TECHWIN
118
SM411
Vision Board Interface
NO. PART NO. PART NAME Q'TY TYPE REMARK
1
J90831098A HEAD1 FIDUCIAL CAMERA CABLE ASSY SM33-VIS001
2
J90831100A HEAD2 FIDUCIAL CAMERA CABLE ASSY SM33-VIS003
3
J90831110A CALIBRATION_CAMERA_CABLE_ASSY SM33-VIS013
4
J90831102A HEAD1 FLY CAM PWR/SYNC CABLE ASSY SM33-VIS005
5
J90831104A HEAD2 FLY CAM PWR/SYNC CABLE ASSY SM33-VIS007
6
J90831105A HEAD1 FLY CAM SIG CABLE ASSY SM33-VIS008
7
J90831107A HEAD2 FLY CAM SIG CABLE ASSY SM33-VIS010
8
J90831101A NEXTEYE B/D I/F CABLE ASSY,HR70 SM33-VIS004
9
J90831109A NEXTEYE B/D I/F CABLE ASSY,MEGA SM33-VIS012
10
J90831099A FLAT_FID. CAMERA CABLE ASSY SM33-VIS002
11
J90831103A FLY CAM PWR/SYNC EXT CABLE ASSY SM33-VIS006
12
J90831106A FLY CAM SIG EXT CABLE ASSY SM33-VIS009
13
J90831108A FLYING CAMERA I/F CABLE ASSY SM33-VIS011
14
15
16
17
18
19
20
21
22
23
24
25
26
27
P art L is t
