SM411 Technical Reference(User)-Distribution - 第29页
Page SAMSUNG TECHWIN 29 SM411 Y -B al l S cr ew Ass’y F . R R . L 1 3 3 6 2 5 6 6 8 9 1 0 1 1 4 4 5 8 9 1 0 1 1 1 2 6 8
Page
SAMSUNG TECHWIN
28
SM411
Y1-Frame Ass’y
NO. PART NO. PART NAME Q'TY TYPE REMARK
1 J3212022A PHOTO SENSOR
3
2 J66071013A LM GUIDE
1
3 J32110015B Photoelectric Switch
4
4 J70541102A FRONT SENSOR BKT1
1
J70541102A
5 J70541103A FRONT_SENSOR_BKT2
1
J70541103A
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
P art L is t
Page
SAMSUNG TECHWIN
29
SM411
Y-Ball Screw Ass’y
F
.
R
R
.
L
1
3
3
6
2
5
6
6
8
9
10
11
4
4
5
8
9
10
11
1
2
6
8
Page
SAMSUNG TECHWIN
30
SM411
Y-Ball Screw Ass’y
NO. PART NO. PART NAME Q'TY TYPE REMARK
1 J3108064A SERVO MOTOR
2
2 J66121007A COUPLING
2
3 J70541005A Y_MOTOR_BLOCK
2
J70541005A02
4 J6601124A SUPPORT UNIT
2
5 J72541006A STOPPER_Y_BALL_SCREW_FRONT
2
J72541006A
6 J66061002A BALL SCREW
2
7 J6061601000 DOWEL PIN
8
8 J72541004A STOPPER_Y_BALL_SCREW
2
J72541004A01
9 J6601020A BALL BEARING
2
10 J70541030A BRG_HOUSING_Y
2
J70541030A
11 J70541006A BS_REAR_SUPPORT
2
J70541006A
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
P art L is t
