Page SAMSUNG TECHWIN 36 SM411 H ea d As s’y ( A) - (2/ 2) A B 3 4 3 3 3 5 3 6 3 7 - C 3 8 3 9 4 0 4 1 4 2 4 3 4 4 3 7 - B 3 7 - A
Page
SAMSUNG TECHWIN
35
SM411
Head Ass’y (A) - (1/2)
A B
1-C
1-B
1-D
1-E
1-F
1-A
2
3
5
4
6
6
6
46
50
6
7
8
9
8
10
11
11
12
13
22
23
14
17
19
20
26
16
15
18
18
21
24
25
27
30
29
26
31
32-A
32-B
32-C
28
30
29
26
31
32
32
49
48
47
45
11
Page
SAMSUNG TECHWIN
36
SM411
Head Ass’y (A) - (2/2)
A
B
34
33
35
36
37-C
38
39
40
41
42
43
44
37-B
37-A
Page
SAMSUNG TECHWIN
37
SM411
Head Ass’y (A)
NO. PART NO. PART NAME Q'TY TYPE REMARK
1-A
J90831175A Z1 MOTOR CABLE ASS'Y SM33-MD019
1-B
J90831176A Z2 MOTOR CABLE ASS'Y SM33-MD020
1-C
J90831177A Z3 MOTOR CABLE ASS'Y SM33-MD021
1-D
J90831178A Z4 MOTOR CABLE ASS'Y SM33-MD022
1-E
J90831179A Z5 MOTOR CABLE ASS'Y SM33-MD023
1-F
J90831180A Z6 MOTOR CABLE ASS'Y SM33-MD024
2 J7055656A Z-TENSION BRACKET
6
J7055656A
3
J7155518A PULLEY (Z-AXIS 1) 6
J7155518A
4
J3212048A MICRO PHOTO SENSOR 6
5 J7155541A PIN
12
J7155541A
6
J71550511B STOPPER
12
J71550511B
7
J6602076A TIMING BELT 6
8 J6601140A
BALL BEARING 12
9
J7155565A PULLEY (Z-AXIS 2) 6
J7155565A
10
J7055658A PULLEY PIN
6
J7055658A
11
J6607055A LM GUIDE 6
12
J7055552A SENSOR BRACKET R-H 3
J7055552A
13 J3212027A MICRO PHOTO SENSOR
3
14 J6711180B ROTARY JOINT
6
15 J7155509A SPLINE ALIGNER CAP
6
J7155509A
16 J7155510A JOINT
6
J7155510A
17 J6049000250 WASHER WAVY .62OD x .48ID x .09
6
18
J6601088A BALL BEARING 12
19
J7055554A SPACER 6
J7055554A
20
J7055545B SPLINE ALIGNER 6
J7055545B
21
J71550508B SLIDE BODY 6
J71550508B
22
J7055548A SPRING 6
J7055548A
P art L is t
