Spare parts

User Manual

POS Article no. Amount Description SK

1 60.001.382 1 Controller Berghof CEDIO-P24/24/2-1131 2

2 60.001.419 1 Brake resistor WH50 2,2 Ohm 2

3 60.002.039 3 Couple-relay 8A DC 24V 2

4 60.002.083 1 Relay safety PNOZ S3 2

5 60.002.089 1 Relay safety PNOZ S2 2

6 60.006.043 1 Line safety switch B 20A 1pole 2

7 60.006.242 1 Contactor 20A AC-1 24V DC LC1DT20BD 2

8 60.009.051 2 Motor regulator SC5-CAN 2

9 60.009.057 1 Motor controller DC2Q-AS 2

10 60.009.063 1 Interface module AMI 4.0 2

11 60.010.096 1 Power supply QS20.241 1 phase 20A 2

12 60.031.012-01 1 Relays opto coupler Maxi-MW-8-30 2

13 60.031.007-01

EMV Mains filter FN2060-10-06 250V 10A 3

The spare part key (SK) is used to categorize our spare parts: SK = 1 is a wearing part which is not covered

by the warranty. SK = 2 is a component with a limited lifetime. SK = 3 is a component of high reliability.

69.150.1464

13.02.17 - 7

Spare parts

User Manual

8 - 13.02.17

Spare parts

User Manual

POS Article-No. Amount Designation SK

Further electric components

1 50.007.694

1 Cable 12pol for BG75x50/40V 2

2 50.007.696

1 Cable 4 pol. for BG75x50/40V 2

3 60.001.417

1 Control panel Berghof AOPT570 2

4 60.002.102

1 Safety switch interlock PSEN ma1.4p-50 2

5 60.002.103

2 Safety switch PSEN ma1.4p-52 2

6 60.003.136

1 LED signal lamp-green 2

7 60.003.140

1 LED signal lamp-clear 2

8 60.003.151

1 Alarm horn 2

9 60.004.021-02

2 Coupling socket M12 5M PVC 2

10 60.004.222-02

2 Coupling socket M8 5m PUR-OB HGF 2

11 60.004.307-02

3 Coupling socket KUG3-M8 5M PVC black 2

12 60.004.375

4 Coupling socket KUG4-M8 5M PVC 4pol. 2

13 60.004.471

1 Coupling socket STG-M8/KUG4-M8 2.0m PUR 2

14 60.004.1261

1 Cable CAN Bus 5pol.für Motor BGxx 2

15 60.006.002

1 Switch MTO Modul 2

16 60.006.024

1 Emergency stop contactor MTOSF 2

17 60.008.013

1 Security switch T0-2-1/EA/SVB 2

18 60.008.172

1 Emergency stop button QRUV 2

19 60.009.072

1 Motor controller DC2Q-ASX 2

20 60.012.281

1 Sensor button WTB4-3P2192 2

21 60.012.351

2 Sensor reflection WL100-2P4439 2

22 60.012.353

4 Reflectionfoil REF-AC1000-28 2

23 60.012.366

2 Sensor button WL27-3P3402S19 2

24 60.014.003-01

1 Sensor NS inductive IQ10-03BPSKT0S 2

25 60.014.077

1 Sensor NS inductive NBB2-8GM25-E3-V3 2

The spare part key (SK) is used to categorize our spare parts: SK = 1 is a wearing part which is not covered by the warranty. SK = 2 is

a component with a limited lifetime. SK = 3 is a component of high reliability.
