FPS 30B_066355_01_ED_GB - 第22页

Spare parts

User Manual

POS Article no. Amount Description SK

1 20.868.205 2 Roll friction gear 1

2 50.004.001-01 2 Cam rollers MCFR19-S 2

3 50.007.1015 2 Motor GR42x40 PLG42K i=16:1 2

4 50.023.795 2 Guiding waggon R 1666 194 23 2

5 51.001.254 4 Compact cylinder ADVU-16-10-P-A 2

6 51.002.007-01 4 Throttle check valve GRLA-M5-QS-4 2

7 51.009.006 6 Coupler FK-M4 2

8 51.012.002-02 2 Sensor proximity switch RZT6-03ZRS-KR0 2

9 51.020.001-01 10 Shock absorber SA10 S N 2

The spare part key (SK) is used to categorize our spare parts: SK = 1 is a wearing part which is not covered

by the warranty. SK = 2 is a component with a limited lifetime. SK = 3 is a component of high reliability.

20.868.959

13.02.17 - 19

Spare parts

User Manual

35.250.100-01

20 - 13.02.17

Switching cam for homing

Spare parts

User Manual

POS Article no. Amount Description SK

1 60.014.003-01 1 Sensor NS inductive IQ10-03BPSKT0S 2

The spare part key (SK) is used to categorize our spare parts: SK = 1 is a wearing part which is not covered

by the warranty. SK = 2 is a component with a limited lifetime. SK = 3 is a component of high reliability.

35.250.100-01

13.02.17 - 21
