DEK Galaxy APi
Machine Standard Configuration
Transport System
Specification
Type
Single piece with 3mm round transport belts, front rail fixed
ESD Compatibility
Black transport belts and guides with surface resistivity of greater than 10
6
ohms
but less than 10
11
ohms.
Width Adjustment
Programmable motorized rear rail
Transport Direction
Left to right
Right to left
Left to left
Right to right
Substrate Handling Size (minimum)
50mm (X) x 40.5mm (Y)
Substrate Handling Size (maximum)
620mm (X)* x 508.5mm (Y)
Substrate Thickness
0.2mm to 6mm
Substrate Weight (maximum)
1kg
Substrate Warpage
Up to 7mm including substrate thickness
Substrate Fixture
Patented over the top clamps
Substrate Handling Features
Soft rail lift / land
Board clamp regulator
Substrate Underside Clearance
Programmable 3mm to 42mm
*Refer to the Long Board Printing Capability Specification for Under Stencil Cleaner and Fabric sizes
Process Parameters
Specification
Print Pressure
0kg to 20kg
Print Speed
2mm/sec to 300mm/sec
Print Gap
0mm to 6mm
Substrate Separation
Speed: 0.1mm/sec to 20mm/sec
Distance: 0mm to 20mm
Print Modes
ProFlow®
Print / Print
Print / Flood
Flood / Print
Adhesive
Paste Knead
Programmable: number; period; on demand
4
DEK Galaxy APi
Machine Standard Configuration
Vision
Specification
Vision System
Cognex
Fiducial Recognition
Automatic fiducial teach and find incorporating 0.1mm fiducial capture
Fiducials
2 or 3
Fiducial Types
Synthetic fiducial library or unique pattern recognition
Fiducial Size
0.1mm to 3mm
Fiducial Locations
Anywhere on substrate
Fiducial Error Recovery
Auto lighting adjustment
Auto fiducial search
Camera Lighting
Software controlled programmable LED lighting
Operating Environment
Specification
Temperature
10° to 35° C (50° to 95° F)
Humidity
30% to 70% relative humidity (non-condensing)
Services
Specification
Voltage
100 Volts to 240 Volts +/- 10%. Single phase 50/60Hz
Maximum Current at 115V
20 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
10 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤ 25 Amps is required to be fitted in line with the
machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
840kg boxed (dependent upon configured options selected with machine)
680kg unboxed (dependent upon configured options selected with machine)
Approximate Dimensions
2060mm x 1500mm x 1570mm (81.1” x 59” x 61.8”)
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
Acoustic Noise Level
Less than 70dB 2003/1/EC
5
DEK Galaxy APi
Machine Productivity Options
Process
Specification
Print Method
Paste Dispenser
Paste roll height monitor
ProActiv
ProFlow®
ProFlow® low volume head
Printing Environment Control
Static – Air Ioniser
Temperature – Temperature Control Module (TCM)
Stencil Frame
VectorGuard®
Universal screen frame adaptor
Adjustable Stencil Mount (ASM)
Frame variants – Fully adjustable to accommodate frame sizes in the range of
305mm** to 736mm (12”** to 29”) by 38mm height.
Image position: Centre / Front / Custom
Under Stencil Cleaning
Cyclone Duo. Specify length (300mm, 400mm, 460mm, 515mm)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Singulation
Virtual Panel Tooling (VPT)
Software & Communications
Off Line Editor (OLE)
GEM on TCP/IP
Remote Event Monitoring (REM)
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® tooling
Substrate Support
Single piece conveyor with flat belts (heavy boards)
High Throughput Conveyor (HTC) with round belts
Remote board stop (for use with heavy board option)
Substrate Fixture
Over Top Snuggers (OTS)
Snuggers (edge clamping)
Foil-less clamps
Vision
Specification
HawkEye® 1700 Functionality
Enabled (camera included)
HawkEye®
HawkEye® Bridging
2Di Inspection
Basic stencil and board
Advanced stencil and board
Other
Specification
Product Data Capture
Verification & Traceability
ProDEK closed loop
