KGX_w-ATS(YG)_PL - 第10页
Shutter+Racklook Magazine 4 3 KGX-0505 44 43 6 5 43 42 45 13 50 43 19,20 8 18 39 15 12 15 48 21 16 3 49 9 10 41 43 50 1 46 51 42 14 17 40 47 14 13 43 8 7 10 40 46 1 14 39 15 15 14 12 11 48 3 2 54 30 35 36 52 31 24 26 38 …
Rack Stage
Magazine
42
KGX-0505
3
22
716
22
2
23
7
21
11
25
8
21
27
18
20
29
15
12
30
13
25
28
8
1
6
22
24
23
22
4
9
26
10
11
14
17
19
11
25
9
22
5
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KGX-M17D1-L0X RACK STAGE L ASSY 2
2 KGX-M17D1-R0X RACK STAGE R ASSY 2
3 KGX-M17D2-00X SHUTTER C ASSY 2
4 KGX-M17D3-00X SHUTTER L ASSY 2
5 KGX-M17D4-00X SHUTTER R ASSY 2
6 KGX-M17D5-00X RACK LOCK ASSY 4
7 KGX-M1785-L0X BRACKET,SENSOR L 2 for Left
8 KGX-M1785-R0X BRACKET,SENSOR R 2 for Right
9 KGX-M178S-00X BOLT 24
10 KW6-M717G-A0X SENSOR ASSY 4
11 KV5-M1134-00X SENSOR PALLET 1
12 KGX-M1781-00X PLATEBOTTOM,MAGAZINE 1
13 KGX-M1782-00X GUIDE,MAGAGINE 2
14 KGX-M1783-00X PIN,LOCATE 2
15 KGX-M1784-L0X BLOCK,SENSOR L 1 for Left
16 KGX-M1784-R0X BLOCK,SENSOR R 1 for Right
17 KGX-M1786-01X BASE,SPRING 2
18 KGX-M1787-01X LEAF SPRIG 4
19 KGT-M922C-00X LOW HEAD CAP SCREW 2
20 KH8-M7158-00X STEEL BALL 1 4
21 91317-03005 BOLT HEX.SOCKET HEAD 8 M3X5
22 91317-04006 BOLT HEX.SOCKET HEAD 30 M4X6
23 91317-05010 BOLT HEX.SOCKET HEAD 16 M5X10
24 92907-05200 WASHER PLAIN 16 M4X20
25 92D18-02008 BOLT HEX: SOCKET HEAD 16
26 98903-03008 SCREW BINDING HEAD 4
27 KH8-M7169-00X SCREW 4
28 91317-03006 BOLT HEX.SOCKET HEAD 2 M3X6
29 91317-03010 BOLT HEX.SOCKET HEAD 2 M3X10
30 91317-04012 BOLT HEX.SOCKET HEAD 14 M4X12
Shutter+Racklook
Magazine
43
KGX-0505
44
43
6
5
43
42
45
13
50
43
19,20
8
18
39
15
12
15
48
21
16
3
49
9
10
41
43
50
1
46
51
42
14
17
40
47
14
13
43
8
7
10
40
46
1
14
39
15
15
14
12
11
48
3
2
54
30
35
36
52
31
24
26
38
37
22
27
50
25
34
50
32
28
54
52
50
33
29
23
53
44
43
9
47
4
49
41
Rack Lock
Shuter C Shuter L
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KGX-M178A-00X CYLINDER 4
2 KGX-M178B-00X BASE,SHUTTER CENTER 1
3 KGX-M178C-00X SPACER,CYLINDER 1
4 KGX-M178E-00X BLOCK,SHAFT 1
5 KGX-M178G-00X SHAFT,SHUTTER CENTER 1
6 KGX-M178J-00X SHUTTER,C-R 1
7 KGX-M178K-00X SHUTTER,C-L 1
8 KGX-M178L-00X HOLDER,SHAFT 3
9 KGX-M178M-00X Y LINK 4
10 KGX-M178N-00X SHAFT,LINK 4
11 KGX-M178T-00X SPACER 1,SPC 1
12 KGX-M178U-00X SPACER 2,SPC 4
13 KV4-M1811-00X SIM 2
14 $BF4-M3 JOINT 12
15 $TSCO SPEED CONTROLLER 4
16 KGX-M178D-00X BASE,SHUTTER SIDE 1
17 KGX-M178F-00X BLOCK 2,SHAFT 1
18 KGX-M178H-00X SHAFT 2,SHUTTER 1
19 KGX-M178R-00X SHUTTER L 1 for Left
20 KGX-M178P-00X SHUTTER,R 1 for Right
21 KGX-M178V-00X SPACER 3,SPC 1
22 KGX-M1787-01X LEAF SPRIG 2
23 KGX-M1791-00X BASE,LOCK 1
24 KGX-M1792-00X HOLDER 1,SHAFT 1
25 KGX-M1793-00X SHAFT,LOCK 1
26 KGX-M1794-00X HOLDER 3,SHAFT 1
27 KGX-M1795-01X NAIL,LOCK 1
28 KGX-M1796-00X BRACKET,SENSOR 1
29 KGX-M1797-00X SHAFT,STOPPER 1
30 KGX-M1798-00X WASHER 1
31 KGX-M1799-00X LINER BALL BUSH 1
32 KW6-M717G-00X SENSOR ASSY 1
33 KGX-M179B-00X BUSH 1
34 KGX-M179C-00X LEVER 1
35 KGX-M179D-00X SPG. 1
36 KGT-M9224-00X STOPPER,BUSHING 2
37 KH8-M7158-00X STEEL BALL 1 2
38 KG7-M7169-00X SCREW 2
39 90114-02J015 BOLT HEX.SOCKET HEAD 4 M2X15
40 90115-02J006 BOLT HEX.SOCKET HEAD 4 M2X6
41 90440-01J020 CIRCLIP 4
42 90440-01J040 CIRCLIP 1
43 90933-03J683 BEARING 8
44 91317-03010 BOLT HEX.SOCKET HEAD 2 M3X10
45 91317-04016 BOLT HEX.SOCKET HEAD 2 M4X16
46 92D18-02012 BOLT HEX.SOCKET HEAD 2 M2X12
47 95304-03700 NUT HEXAGON 2
48 98704-04006 SCREW FLAT HEAD 2
49 98707-03006 SCREW FLAT HEAD 4
50 91317-03008 BOLT HEX.SOCKET HEAD 6 M3X8
51 91317-04012 BOLT HEX.SOCKET HEAD 2 M4X12
52 91317-03005 BOLT HEX.SOCKET HEAD 6 M3X5
53 91317-04005 BOLT HEX.SOCKET HEAD 2 M4X5
54 92017-04010 BOLT HEX.SOCKET HEAD 1 M4X10
55 98904-03008 SCREW BINDING HEAD 1
56 92907-03600 WASHER PLAIN 2
1
5
Hook
Hook
KGX-1103
36
32
32
63
63
13
42
34
54
2
1
47
58
15
47
16
53
4
52
11,12
50
8
51
55
55
7
40
55
49
27
33
19
30
36
36
28,29
53
31
55
55
17,18
53
55
27
8
21
43
20
52
14
50
9,10
9,10
7
55
62
64
41
26
50
3
50
49
46
6
39
56
61
37
45
57
25
44
24
23
5
55
60
59
54
38
45
22
50
62
65
50
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGX-M18A1-L0X HOOK SUB ASSY L 1
2 KGX-M18A2-00X HAND ASSY 1
3 KGX-M18A3-00X PLUNGER ASSY. 2
4 KGX-M18A4-00X STOPPER ASSY 2
5 KGX-M1811-00X BASE,HOOK 1
6 150 BRACKET,MOTOR HOOK 1
7 KGX-M1813-00X STAY,GUIDE 4
8 KGX-M1814-00X PLATE 1,GUIDE 2
9 KGX-M1815-L0X GUIDE 1,HOOK 2 for Left
10 KGX-M1815-R0X GUIDE 1,HOOK 2 for Right
11 KGX-M1816-L0X GUIDE 2,HOOK 1 for Left
12 KGX-M1816-R0X GUIDE 2,HOOK 1 for Right
13 KGX-M1817-00X BELT,HOOK 1
14 KGX-M1818-00X BASE,SENSOR 1
15 KGX-M1819-00X GUIDE,CABLE 1
16 KGX-M181A-00X BRACKET,GUIDE 1
17 KGX-M181B-L0X BRACKET,GUIDE L 1 for Left
18 KGX-M181B-R0X BRACKET,GUIDE R 1 for Right
19 KGX-M181C-00X BRACKET,DUCT 1
20 KGX-M181D-00X BRACKET,SENSOR 1
21 KGX-M181E-00X SENSOR,E3TSL24 1
22 KGX-M181F-00X SHAFT 2,PULLEY 1
23 KGX-M181G-00X HOLDER,PULLEY 1
24 KGX-M181H-00X COLLAR 1 1
25 KGX-M181J-00X WASHER 1 2
26 KGX-M181K-00X COVER,SENSOR 2
27 KGX-M181L-00X COVER 1,HOOK 2
28 KGX-M181M-L0X COVER 2,HOOK L 1 for Left
29 KGX-M181M-R0X COVER 2,HOOK R 1 for Right
30 KGX-M181N-00X COVER 3,HOOK 1
31 KGX-M181P-00X POST 1,COVER 4
32 KGX-M181R-00X SENSOR, UMTR15DTV1P 1
32-1 KGX-M652J-10X SENSOR, HOOK CHK 1 (2005/5/17) MB40005 OK
33 KGX-M181S-00X CABLE GUARD 1
34 KGX-M181T-00X COVER,HARNESS 1
35 KGX-M655A-03X SWITCH,OPTICAL 2
36 K16-90101-06X BOLT:TP 6 M4X6
37 KB0-M223E-00X COLLAR 2 1
38 KB0-M2255-01X PULLEY,5 1
39 KC0-M1751-00X PULLEY,1 1
40 KH2-M1819-00X VALVE 1 1
41 KH5-M655A-02X FIBER 1
41-1 KGX-M652U-10X SENSOR, PLT SET 1 OK
42 KV4-M1826-00X BELT MOTOR 1
43 90115-02J008 BOLT HEX.SOCKET HEAD 2
44 90933-01J200 BEARING 2
45 90933-03J696 BEARING 2
46 90K63-001334 AC SERVO MOTOR 1
47 91317-03005 BOLT HEX.SOCKET HEAD 4 M3X5
48 91317-03006 BOLT HEX.SOCKET HEAD 4 M3X6
49 91317-03008 BOLT HEX.SOCKET HEAD 6 M3X8
50 91317-03010 BOLT HEX.SOCKET HEAD 16 M3X10
51 91317-03020 BOLT HEX.SOCKET HEAD 2 M3X20
52 91317-03025 BOLT HEX.SOCKET HEAD 6 M3X25
53 91317-04006 BOLT HEX.SOCKET HEAD 8 M4X6
54 91317-04010 BOLT HEX.SOCKET HEAD 3 M4X10
55 91317-05008 BOLT HEX.SOCKET HEAD 34 M5X8
56 91317-05010 BOLT HEX.SOCKET HEAD 4 M5X10
57 91317-05025 BOLT HEX.SOCKET HEAD 1 M5X25
58 92017-05010 BOLT BUTTON HEAD 3
59 92907-04200 WASHER PLAIN 1
60 92907-05200 WASHER PLAIN 2
61 92907-05600 WASHER PLAIN 4
62 92A08-03303 SET SCREW M3X3 2
63 92D18-02006 BOLT HEX.SOCKET HEAD 4
64 KGX-M652T-10X SENSOR, PLT SET 1
65 KGW-M1804-22X GUIDE PALLET C 1
