N7202A047B - 第248页

36-C 交換台車 (30連):N PM-W Feeder C art(30-Slot):NPM -W パーツレイアウト Kit No. キット品番 Kit Name キット名称 N610119860A A セクシ ョンNo. PARTS LAYO UT Section No. - - O121 ( FN610119860 AA-46-3 ) LAYOUT

100%1 / 976
Ref No. Remarks R
1
Q'ty
36-B
交換台車(30連):NPM-W
Feeder Cart(30-Slot):NPM-W
ｲﾗｽﾄNo.
Part No.
品　　名品　　番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610119860AA
Part Name
備　　　考
セクションNo.
PARTS LIST
Section No.
R
3
BAR
1
P017 N210143823AC
BAR
1
P018 N210143824AC
COLLAR
2
P019 N210132485AA
SHAFT
2
P020 N210132483AA
SHAFT
1
P023 N210143826AB
CAM
2
P024 N210110192AB
BLOCK
1
P025 N210143827AB
BLOCK
1
P026 N210143828AB
POST
2
P027 N210143829AA
BLOCK
1
P028 N210132484AA
KEY
2
P030 N210110190AA
SPRING
1
P031 N210143831AB
SPRING
1
P032 N210091473AD
SPACER
2
P037 N210103057AB
SHAFT
1
P045 N210147064AA
COLLAR
2
P049 N210151273AA
CHUTE
1
P625 N210158039AH
COVER
1
P626 N210143868AD
BRACKET
2
P632 N210147065AC
BEARING
2
N027 MTNB001762AA NATV10-PP-A-00
SNAP-RING
2
N028 XUB10FP
C-Snap for shaft Ring 10 Steel Parkerizing black
BOLT
4
N030 N510017535AA
SSS 003 Hexagon socket button head screw M4X8-10.9 A2S (Trivalent)
PIN
6
N035 KXF0CXKAA00 1017003-60012
SCREW
2
N036 N510018451AA
Hexagon socket set screw Flat point M6X16-45H A2J (Trivalent)
BUSH
4
N038 MTNB001273AA TLFSN20-11.5
PIN
2
N044 N510020617AA MMS6-10
JOINT
1
N046 N510066607AA KQ2L06-00A
JOINT
1
N047 KXF09ZBAA00 KQ2P-06
SPRING-PIN
2
N049 N510029332AA 1017003-30016
SCREW
1
N057 N510018257AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent)
TAPE
1
N601 KXF0DXNAA00 AGF-100 t=0.18 W=100mm L=10m
BUSH
2
N602 N348TE024T TE-024
CABLE-SUPPORT
6
N650 N510048517AA FT4
CABLE-SUPPORT
1
N651 N510065712AA HC-0M
O120
-
-
( FN610119860AA-46-2 )
36-C
交換台車(30連):NPM-W
Feeder Cart(30-Slot):NPM-W
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
N610119860AA
セクションNo.
PARTS LAYOUT
Section No.
-
-
O121
( FN610119860AA-46-3 )
LAYOUT
Ref No. Remarks R
1
Q'ty
36-C
交換台車(30連):NPM-W
Feeder Cart(30-Slot):NPM-W
ｲﾗｽﾄNo.
Part No.
品　　名品　　番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610119860AA
Part Name
備　　　考
セクションNo.
PARTS LIST
Section No.
R
3
BUSH
2
P012 N210184998AA
SHAFT
2
P013 N210143819AC
COLLAR
4
P014 MTPA015726AA
STOPPER
2
P015 N210146558AA
WASHER
4
P016 MTPA021891AA
WASHER
4
P046 N210118289AA
WASHER
4
P047 N210118290AA
BLOCK
2
P048 N210105678AA
PLATE
1
P052 N210184994AA
SPACER
4
P053 MTPA015727AA
PLATE
1
P054 N210184995AB
PLATE
1
P055 N210184996AB
PLATE
2
P056 N210185001AA
BRACKET
1
P613 N210184999AC
COVER
1
P615 N210143852AB
BRACKET
2
P619 N210143857AA
COVER
1
P634 N210143904AA
COVER
1
P635 N210143910AC
COVER
1
P636 N210143909AC
BRACKET
1
P637 N210143908AB
FRAME
2
N016 MTNK009419AA FRAME012-30X60 L=413 2-M8X24
NUT
32
N018 KXF0ATGAA00 SFB-002
CAP
32
N019 MTPZ002125AA
BOLT
2
N022 MTNK007872AA
Hexagon socket head cap screw M12X30-10.9 A2J (Trivalent)
BOLT
2
N023 N510032463AA MMSB13-20
BOLT
6
N051 N510022750AA
Hexagon socket head cap screw M4X10-10.9 A2S (Trivalent)
WASHER
6
N052 N510018498AA
Round finish plain washer 4 10H A2S (Trivalent)
COUPLER
1
N053 N510056986AA MA-MS-PCL4-06(CS35877-0)
BOLT
2
N055 N510017429AA
Hexagon socket head cap screw M6X12-10.9 A2S (Trivalent)
WASHER
4
N056 N510018502AA
Round finish plain washer 6 10H A2S (Trivalent)
O122
-
-
( FN610119860AA-46-3 )
